6

Tail Landing Gear

PA2x8mm Screw
2
PM2x8mm Screw
1
M2 Nut
1
7

Rudder Pushrod

PM2x10mm Screw
2
Horn
2mm
Clevis
d2xD4x4mm
PM2x10mm
8

Elevator Pushrod

Clevis
M2 Nut
PM2x8mm
Plastic Collar
Ø1mm pilot holes for World Models tri-horn are pre-drilled.
Please look for pin-hole marks at side of control surfaces.
Pushrod
Ø 1.4x520mm
Fuel Tube
Fuel Tube
d2xD4x4mm
1mm
Pushrod
Ø 1.4x490mm
57mm
P.5
1mm
PA2x8mm
Pushrod
Ø 1.4x520mm
27mm
Bottom View
Bottom View
