7
Tail Landing Gear
PA2.6x12mm Screw
2
PM2x10mm Screw
1
M2 Nut
1
2.1mm Collar
1
8
Elevator Pushrod
PB2x10mm Screw
4
Bottom View
9
Rudder Pushrod
PB2x10mm Screw
2
Bottom View
Bottom View
Ø1mm pilot holes for World Models horn are pre-drilled.
Please look for pin-hole marks at under side of control surfaces.
Ø1mm pilot holes for World Models horn are pre-drilled.
Please look for pin-hole marks at under side of control surfaces.
P.6
PA2.6x12mm
M2 Nut
Steering Bracket
Fuel Tube
PB2x10mm
d2xD4x4mm
Pushrod
Ø1.4x610mm
Clevis
3mm
set screw
PM2x10mm
TWM PL8210010
CLEVIS WRENCH
Horn
TWM PL8210010
CLEVIS WRENCH
Horn
