BEFORE YOU BEGIN

PARTS LIST
ASSEMBLY
SAFETY PRECAUTIONS
BEFORE YOU BEGIN
1
Read through the manual before you begin, so you will have an overall idea of what to do.
2
Check all parts. If you find any defective or missing parts contact your local dealer. Please DRY FIT
and check for defects for all parts that will require CA or Epoxy for final assembly. Any parts you
find to be defective after the gluing process may be difficult to remove for warranty replacement. The
manufacturer will replace any defective parts. but will not extend to the parts that are good before
gluing to defective parts during assembly.
3
Symbols used throughout this instruction manual comprise of the following : -
Apply epoxy glue.
Assemble left and right
sides the same way.
Peel off shaded portion
covering film.
Drill holes with the specified
diameter (here: 3mm).
3mm
Pay close attention here!
Pierce the shaded portion
covering film.
I N D E X
Apply instant glue
(C.A.glue, super glue.)
Ensure smooth non-binding
movement while assembling.
Cut off shaded portion.
Must be purchased separately!
Do not overlook this symbol!
P . 1
P. 1
P. 2
P. 3 - 11
P. 11
