7

Rudder Pullwire

Screw
PM2x25mm
Nut
M2
M2 Nut
8

Elevator Pushrod

Screw
PM 2 x 22 mm
6
PM 2 x 22mm
Clevis
Fuel Tube
Ø6x5mm
Elevator Pushrod
1.8x 900mm
9

Engine Mount

Screw
PM 4x 25mm
4
Washer
d4 x D12mm
4
Apply thread locker to screws.
Blind nuts are off-centered to keep
the spinner at the fuselage axis.
!
Ø 1mm pilot holes for World
3
Models tri-horn are pre-drilled.
Please look for pin-hole marks at
3
side of control surfaces.
PM2x25mm
2mm
Tri-horn
M3 x 14mm(L)
PM 4x 25mm
d4 x D12mm
102mm
Ø1mm pilot holes for World Models tri-horn are pre-drilled.
Please look for pin-hole marks at under side of control surfaces.
205mm
50mm
Washer
P.5
Fuel Tube
Ø6x5mm
Clevis
Rigging Coupler
1.8x27mm
Copper Tube
235mm
Bottom View
Engine Mount
PL 5111080
Tri-horn
M3x14mm
2mm
