Radio Equipment - THE WORLD MODELS Groovy 90 Instruction Manual

12
Servo Set
LINKAGE CONNECTOR
Set Screw
3 x 3mm
1
Linkage Connector
1
Nut
M2
1
Washer
2mm
2
13

Radio Equipment

Press down the center
1/3 portion
Straper
Elevator Pushrod
Ø1.8x900mm
Plywood
5x61x109.7mm
Rudder Pullwire
Ø1x1080mm
Elevator Pushrod
Ø1.8x105mm
2mm
2mm
Please refer to attached sheet for linkage connector installation.
Elevator Servo Balsa
6x6x41mm
Fuel Tube
Ø6x5mm
RIGGING Z BEND
Ø1.8x27mm
Wing Incidence Angle Adjuster
KM 2x8mm
2mm
2mm
2mm
Install and arrange the servo as shown in the diagram.
Copper Tube
Plywood 5x61x114mm
Plywood
5x61x112mm
Sponge
Rudder Servo
M3 x30mm
PWA2.6x12mm
M3 Nylon Insert Lock Nut
P.7
3mm
Included with the radio Set.
Throttle Servo.
Balsa
Throttle Pushwire
6x6x41mm
Ø1.2x270mm
Throttle Servo
Outside
Inside
