Continuous Drainage

Cautions when using the unit with continuous drainage
This dehumidifier is for home use. If you use it with continuous drainage, make sure to check the unit at least once every 2 weeks for
a dirty filter or clogged drain hose.
If you are using a drain hose, make sure that the temperature around the hose does not drop below 0¡C. Water in the hose might
freeze causing water to spill and wet the floor and the unit.
Cover the end of the hose with netting to prevent insects from entering.
The AUTO OFF function also works during CONTINUOUS DRAINAGE. 12 hours after the start of operation, the unit will automatically
stop. The AUTO OFF function can be canceled as described below.
Canceling the AUTO OFF function
Before using CONTINUOUS DRAINAGE
As explained in "Preparations before use" (
automatically after 12 hours of normal operation. If you do not wish this function to work during continuous
drainage, you can cancel it as described below.
Plug in the power plug.
While pressing the WIDE SWING button in stopped condition, keep
the POWER ON/OFF button pressed for at least 3 seconds.
When setting is completed, there will be a beep sound, the
LED display indicates [
lights for 5 seconds.
To reactivate the AUTO OFF function, disconnect the
power plug from the wall outlet and carry out the procedure
described in
above. After 3 seconds, the beep sounds
to indicate that setting is completed.
CONTINUOUS DRAINAGE is possible, if there is a place to drain water nearby. Make sure to stop
operation, disconnect the power plug from the wall outlet and carry out the following procedure.
Open a drain hose hole.
1
Remove the water tank. Using a screwdriver, punch a hole at the drain hose hole
located at the back of the unit. Smoothen the edge of the hole with a file etc.
Attach the elbow joint to the other end of the hose inserted into the continuous drainage hole.
2
Remove the drainage tank. Pull down the drain stopper located at the upper right inside the casing.
Put your finger behind the rubber packing on the drain stopper. Then pull the rubber packing off toward
the front and remove the drain seat at the same time.
* These are important parts you will need when not using CONTINUOUS DRAINAGE. Keep the rubber packing and drain seat in a safe place.
Attach the elbow joint to the other end of the hose inserted into the continuous drainage hole.
Commercial hose, 15mm internal
diameter.
Elbow joint
Insert the elbow joint into the drainage outlet of the unit.
3
Insert the elbow joint into the drainage outlet of the unit all the way to the joint base.
Re-install the water tank.
4
The unit does not operate without the water tank in place.
(The unit is turned off with water-brimmed direction device in the unit.)
Positioning of the
drainage hose for
continuous
dehumidification
To stop continuous drainage and return
the dehumidifier to its original state
) the AUTO OFF function will shut down the unit
page
] and the FULL TANK indicator
Drain hose hole
Insert more
Front view
than 10mm
into hose.
The hose must
be below the
At least 10cm
level of the
drainage hole.
Pull the joint elbow toward you and pull it out of the continuous drainage hole together with the hose.
Align the rubber packing with the hole in the drain seat, then insert these two parts firmly into the hole
of the drain stopper.
WIDE SWING button
Press together
for at least
3 seconds
Drain hose hole
Drainage outlet
Elbow joint
Rubber packing
Drain stopper
Drain seat
* Before inserting the hose into the
continuous drainage hole, remove
the rubber packing and drain seat.
The end of the
Do not bend
hose should
the hose.
not come in
direct contact
with water.
POWER ON/OFF button
Rear view
Elbow joint
E-15
