DEHUMIDIFIER
OPERATION MANUAL
Model
DW-D12A
High - Density 7,000
The number in this technology mark refers to the approximate
quantity of ions per cm
3
of air released from the dehumidifier
equipped with a high-concentration Plasmacluster ion generating
unit which was measured at the center point (1.2 meter height
above the floor) of high-concentration Plasmacluster 7,000
applicable floor area room(temperature 28°C, humidity 50%)
when the dehumidifier was placed against the wall and runs in
laundry mode and the swing louver is set to full open position.
Device of this mark is a trademark of
Sharp Corporation.
Plasmacluster is a registered trademark
or a trademark of Sharp Corporation.
Do not use the product for commercial purposes.
CONTENTS
PAGE
2
3
7
8
9
11
13
14
16
19
20
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sharp DW-D12A-W
Summary of Contents for Sharp DW-D12A-W
-
Page 1: Table Of Contents
SPECIFICATIONS TROUBLESHOOTING Device of this mark is a trademark of Sharp Corporation. Plasmacluster is a registered trademark or a trademark of Sharp Corporation. Do not use the product for commercial purposes. -
Page 2: Features
SAFETY PRECAUTIONS FEATURES The dehumidifier deodorizes, cleans and quickly To prevent any possible injury to WARNING persons or damage to property, dries clothes hung up in the room by using the be sure to follow the basic safety precautions, including the high-concentration Plasmacluster Ion (PCI) following: technology and the powerful dehumidifying... - Page 3 CAUTION In case of an exception (e.g., burnt smell), be sure to immediately shut the unit down and remove its power plug. Make sure there is no dust on the power plug and insert it into the outlet Power Plug, Power Cord completely.
-
Page 4: Parts Name
PARTS NAME Front View Before moving the main unit, always stop the operation and dispose the Control panel water in the water tank. Operate the unit only on level, stable surfaces. Louver (If water leaks from the dehumidifier and soaks the furniture in the room, electric (Do not shake it shock, electric leakage or fire may be caused.) with your hand) -
Page 5: Before Use
BEFORE USE WHAT YOU NEED TO KNOW WHEN MOVING Take out the Packaging Always hold the handle and product take out from the box material from the box Stop the dehumidifier, Bind the power cord, and move pull out the water tank, it together with the handle. -
Page 6: Auto Defrost
HOW TO OPERATE AUTO DEFROST CONTROL PANEL During defrosting, the defrosting indicator is on, the compressor stops, and the fan keeps rotating at the highest speed. After the defrosting ends, the dehumidifying function starts, the compressor restarts, and the fan resumes the preset speed. When the temperature sensor fixed on the copper pipe of evaporator detects that the dehumidifier temperature is lower than or equal to -1°C (and the relative room temperature is lower than or equal to 13°C), the dehumidifier will start the automatic defrosting procedure, namely, the dehumidifier defrosts automatically after... -
Page 7: Other Functions
OTHER FUNCTIONS AUTO STOP AT TANK FULL 4. AUTO: The Auto indicator is turned on, and the dehumidifier dehumidifies according to the preset humidity. You can press the HUMIDITY SELECTION (AUTO MODE) button to set the desired humidity. The setting order is as follows: If the water in the water tank reaches the set level when the dehumidifier operates in the dehumidifying 60%RH (default) >... -
Page 8: How To Drain
HOW TO DRAIN After the water tank is removed, the Tank full indicator is on and the operation stops. WATER TANK CONTINUOUS DRAINPIPE When the water tank is full, the dehumidifier will stop running Unplug the power plug FULL automatically. You need to empty the water tank and put it back into the main unit. -
Page 9: Care And Maintenance
CARE AND We recommend periodical cleaning for a long, clean and sanitary use! MAINTENANCE AIR INLET WATER TANK Once a week Empty the water tank, and Remove the Remove the dust then remove its cover water tank cover with vacuum cleaner Open it slowly from the corner Clean it with a white tableware cloth After use for a long term, water... -
Page 10: Main Unit
SPECIFICATIONS Model DW-D12A MAIN UNIT 220V-240V/50Hz Power Supply 12L/day 30°C/80%RH Dehumidifying Capacity Use a soft cloth soaked with warm water (lower than 35°C) or neutral detergent (for tableware) to wipe dirt from the surface. 6.5L/day 26.7°C/60%RH Power Consumption 26.7°C/60%RH 160W Wipe the neutral detergent off Standby Status 0.45W... -
Page 11: Troubleshooting
32°C). indicator is still blinking. The unit may malfunction. such as C0 and C3 Please contact SHARP authorized service centre. When the currently When the humidity setting button is not pressed during operation of displayed humidity is...
