Note: On listing the interface configuration, the PIN value is displayed in encrypted
mode. For the above example:
Example:
umts2/0 AT config>show conf
; Showing Menu and Submenus Configuration ...
; ATLAS Router 2 8 Version 10.5.1-Alfa
pin ciphered 0xFEC7DB8210108C93

3.9. SPEED

Permits you to configure the base interface data speed.
Example:
umts2/0 AT config>speed ?
<9600..460800>
umts2/0 AT config>speed 460800

3.10. UMTS

Permits you to configure UMTS options in the device.
The options are as follows:
Command
DOMAIN
MODE

a) UMTS DOMAIN

Permits you to select the data mode to be used.
The normal mode used for UMTS and supported by the carrier is PS (Packet Service).
Example:
umts2/0 AT config>umts domain ?
cs Circuit switched only
ps Packet switched only
cs+ps CS+PS
umts2/0 AT config>umts domain ps

b) UMTS MODE

Permits you to select the type of network to connect to.
Example:
umts2/0 AT config>umts mode ?
automatic
gprs
wcdma
umts2/0 AT config>umts mode wcdma

3.11. WAIT-TIME

Permits you to configure the maximum connection wait time when the connection is GSM.
Value in the specified range
Functions
Selects the type of data domain to use (Data, Packets or Both).
Selects the network mode going to be used (GPRS, WCDMA or AUTO).
Automatic
GPRS only
UMTS only
