5 Install the front drive bezel. See "Installing the Front Drive Bezel" on
page 66.

Removing a Hot-plug Hard Drive Blank

NOTICE:
To maintain proper system cooling, all empty hot-plug hard-drive bays
must have drive blanks installed. If you remove a hot-plug hard drive from the
system and do not reinstall it, you must replace the drive with a drive blank.
Remove the drive blank as you would the hot-plug hard drive:
1 Remove the front bezel, if attached. See "Removing the Front Drive
Bezel" on page 66.
2 Open the hot-plug drive blank release handle to release the blank. See
Figure 3-13.
3 Slide the drive blank out until it is free of the drive bay.

Installing a Hot-plug Hard Drive Blank

Install the drive blank as you would a hot-plug hard drive:
1 Remove the front bezel, if attached. See "Removing the Front Drive
Bezel" on page 66.
2 Open the handle on the drive blank.
3 Insert the drive blank into the drive bay until the blank is fully seated.
4 Close the handle to lock the blank in place.
5 Install the front bezel. See "Installing the Front Drive Bezel" on page 66.

Diskette Drive

The 3.5-inch drive bay supports an optional standard diskette drive.

Removing the Diskette Drive

CAUTION:
Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
