CAUTION:
sufficient time for the processor and heat sink to cool before handling.
NOTICE:
processor.
12 Remove the processor(s). See "Removing a Processor" on page 134.
13 If applicable, remove the SAS/SATA backplane. See "Removing the
SAS/SATA Backplane" on page 149.
14 Carefully route any loose cables away from the edges of the system board.
15 Remove the system board from the chassis. See Figure 3-44.
Pull and hold the blue system board release pin.
a
While holding the release pin and the system board touch point, slide
b
the system board towards the front of the system, and lift the board
out of the chassis.
Figure 3-44. Removing and Installing the System Board
1
156
Installing System Components
The processor and heat sink can become extremely hot. Allow
To prevent damaging the processor, do not pry the heat sink off of the
2
3
4
