2-8 Other Connectors Configuration

This section lists out all connectors configurations for users' reference.

2-8.1 On Board FAN Connectors

PS/2 Mouse
Main Power
(on top)
PS/2 K/B
(underside)
USB0
mPGA478B
(on top)
J2 Aux Power
(underside)
USB1
RT1
+12V Power
1 2
J4
3 4
P4X266A
RT2
AGP 4X
LPC I/O
Controller
PCI 1
1 4
CD_IN1
1 WOL1
PCI 2
AC'97
Audio
VIA
PCI 3
VT1611A
16
PCI 4
1
USB3
JP11
1
PCI 5
SCR1 PCI 6
CNR
• These fan connectors support CPU/System/AGP/Chassis cooling fan with
+12V. When connecting the wire to FAN connectors, users should make
sure that the red wire is for the positive current and should be connected
to pin +12V, and the black wire is Ground and should be connected to pin
GND. Sensor Fan supports Hardware Monitor chipset on board to imple-
ment the hardware monitoring function.
• For fans with speed sensors, each rotation of the fan blades will send out
2 electric pulses, by which System Hardware Monitor will work out the fan
rotation speed by counting the pulses.
ZD1
1
VIA
FAN3
1
ON DIP
1 2 3 4
SW1
Clock
Generator
Li
VIA
Battery
VT8233A
JP10
1
JBAT1
1
FAN4
1
HDD/LED IR PWR SMI
JP15 JP16
30
1
1
1
SPK RST PWR LED SUS LED
SENSOR
+12V
GND
Fan1/Fan2
CPU FAN Connector
(FAN1, yellow, sensor)
S y s t e m FA N C o n n e c t o r
(FAN2, yellow, sensor)
AGP FAN Connector
(FAN3, white, no sensor)
Chassis FAN Connector
(FAN4, white, no sensor)
30
Void(N/C)
+12V
GND
Fan3/Fan4
