2-7.4 Jp16 Suspend to RAM (STR)

• Jp16 is designed to support the S3 mode (Suspend to RAM) of ACP
(Advanced Configuration and Power interface) which is usually integrated
in such operating systems as Win 98se, Win 2000 or Win XP.
• To enable the STR function, you must first set up Jp16, and then enter
"BIOS Setup", then "Power management Setup" to choose the item "ACPI
Suspend Type". In this item, choose S3(STR) mode to enable Suspend to
RAM function.
• With STR enabled, you power off your system with Standby mode, and
you can reboot your system directly to the screen of power-off without
going through the reboot procedures.

2-7.5 Jp11 Flash ROM Write Protection Select

Jp11 is designed to support the "Flash ROM write Protection" function
when you boot your system. Setting Jp11 1-2 closed will protect your
Flash ROM from virus attack every time you boot your system.
Chapter 2 Hardware Setup
Jp16
Suspend
to RAM
1
1-2
Disabled
closed
1
Enabled
2-3
(default)
closed
Flash ROM Write
Jp11
Protection
1
1-2
Enabled
closed
(default)
1
2-3
Disabled
closed
29
