2-8.5 Thermal Sensor Connector Rt1, Rt2 - SOLTEK SL-85DRV3 User Manual

2-8.5 Thermal Sensor Connector RT1, RT2

Mouse
PS/2
Main Power
(on top)
PS/2 K/B
(underside)
USB0
(on top)
J2 Aux Power
USB1 (underside)
RT1
+12V Power
1 2
J4
3 4
RT2
LPC I/O
Controller
1 4
CD_IN1
1 WOL1
AC'97
Audio
VIA
VT1611A
16
1
USB3
JP11
1
SCR1
CNR
1. Connector RT1: A blue thermal resistor is already soldered to
connector RT1 so as to sense the temperature round the mainboad.
What RT1 does is to transmit the thermal signal to BIOS or Hardware
Monitor.
2. Connector RT2: A thermal cable is needed to connect RT2 to on-
board devices such as HDD, Graphics card etc., so as to detect the
temperature generated therein. Please connect the end (a) of the
thermal cable to mainboard RT2 header, and tape another end (b) of
thermal cable on to the device which you want to monitor. After you
have finished the thermal cable installation, you will see the detected
temperature in BIOS setup or Hardware monitor utility.
mPGA478B
1
VIA
P4X266A
FAN3
AGP 4X
1
ON DIP
PCI 1
1 2 3 4
SW1
Clock
PCI 2 Generator
PCI 3
Li
VIA
Battery
VT8233A
PCI 4
JBAT1
1
PCI 5
PCI 6
FAN4
HDD/LED IR PWR
JP15 JP16
1
1
1
SPK RST PWR LED
Chapter 2 Hardware Setup
ZD1
RT1 mounted with
blue Thermal Resistor
To RT2
JP10
1
1
SMI
30
Thermal Cable
SUS LED
33
RT1
RT2
To Devices
