Manitowoc S Model Installation, Use & Care Manual page 14

Installation Instructions
S1470C ICE MACHINES
30"
(76.2 cm)
6.87"
(17.45 cm)
3.24"
(8.23 cm)
25"
(63 cm)
14.77"
(37.52 cm)
20.96"
(53.24 cm)
21.5"
(54.6 cm)
(5.13 cm)
S1870C/S2170C ICE MACHINES
30"
(76.2cm)
30"
(76.2cm)
26.5"
(67.3cm)
20.5"
(52cm)
6.0"
(15.2cm)
S1470C/S1870C/S2170C ice machines are not approved
for use on Manitowoc B570 series bins.
2-2
24.5"
(62.23 cm)
5.5"
(14.0 cm)
2.02"
25"
(63.5cm)
! Warning
5.5"
(14cm)
Electrical
Suction
Line
Liquid
Line
AuCS
Knockout
Drain
1/2"
FTP
Base Drain
Suction
Electrical
Line
Liquid
Line
Drain
1/2"
NPTF
Base Drains
Part Number 000002477 3/08
Section 2
Water Inlet
3/8" FPT
Base
Drain
Water Inlet
3/8" FPT
