Service Handbook

HP 9000 Series 700 Model 743
Go to the Table of Contents
HP Part No. A2636-90604
Edition E1097

Advertisement

Table of Contents
loading

Related Manuals for HP 743

Summary of Contents for HP 743

  • Page 1: Service Handbook

    Service Handbook HP 9000 Series 700 Model 743 Go to the Table of Contents HP Part No. A2636-90604 Edition E1097...
  • Page 2 © Hewlett-Packard Co. 1997 Printing History First Printing: October 1997 UNIX is a registered trademark in the United States and other countries, licensed exclu- sively through X/Open Company Limited. NOTICE The information contained in this document is subject to change without notice. HEWLETT-PACKARD MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS MATERIAL INCLUDING BUT NOT LIMITED TO THE IMPLIED WAR- RANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PUR-...

  • Page 3: Safety And Regulatory Statements

    Hewlett-Packard’s system certification tests were conducted with HP-sup- ported peripheral devices and HP shielded cables, such as those you receive with your computer. Changes or modifications not expressly approved by Hewlett-Packard could void the user’s authority to operate...

  • Page 4: Australia Emc Standards

    Safety and Regulatory Statements Australia EMC Standards This equipment has applied for and received approval to display the Aus- tralian C-Tick mark according to the standards of AS/NZS 2064.1/2:1992 and AS/NZS 3548:1995. VCCI Class A ITE...

  • Page 5: Electrostatic Discharge (Esd) Precautions

    Electrostatic Discharge (ESD) Precautions Electrostatic Discharge (ESD) Precautions Electrostatic charges can damage the integrated circuits on printed circuit boards. To prevent such damage from occurring, observe the following precautions during board unpacking, installation, and configuration: • Stand on a static-free mat. •...
  • Page 6 Electrostatic Discharge (ESD) Precautions...

  • Page 7: Table Of Contents

    Contents Preface Safety and Regulatory Statements iii Safety iii Regulatory Statements iii Emissions Regulations iii Australia EMC Standards iv VCCI Class A ITE iv Electrostatic Discharge (ESD) Precautions v Product Information Product Description 1-2 Technical Information 1-6 Electrical 1-6 Regulatory Compliances 1-7 Environmental Requirements 1-7 Hardware Support 1-9 Field Repair Philosophy 1-9...
  • Page 8 Keyboard 2-7 Memory Controller Circuit 2-7 Memory Map 2-8 I/O Controller ASIC 2-10 Built-in Interfaces 2-11 Audio 2-11 HP Parallel 2-13 RS-232 Ports 2-14 AUI LAN 2-16 SCSI 2-17 PS/2 Ports 1 and 0 2-19 VME Controller ASIC 2-20 Graphics Accessory Cards 2-23...
  • Page 9 Contents Watchdog Timer 2-26 Power Distribution 2-27 Configuration Introduction 3-2 Boot Console Handler 3-3 Overview of the Boot Console Handler 3-3 Using the Boot Console Handler 3-4 Boot From a Device Menu 3-7 Path Configuration Menu 3-9 Primary or Alternate Path Menus 3-10 Console Path Menu 3-10 Keyboard Path Menu 3-11 Mode Configuration Menu 3-12...
  • Page 10 Contents Accessing Firmware Information 3-21 Hardware Information 3-23 ASIC Hardware Component Information 3-25 Graphics Information 3-26 System Configuration Menu 3-27 Graphics Configuration 3-29 Graphics Information in Menus 3-29 Troubleshooting Introduction to Troubleshooting 4-2 Diagnostic Overview 4-2 ISL Environment 4-3 Boot ROM Selftests 4-4 Hardware Initialization Support 4-5 Go/No-Go Selftest Support 4-5 Failure Indications 4-5...
  • Page 11 Contents Boot Options 4-10 Interactive Testing Menu 4-13 Running ODE-Based Diagnostics 4-14 Determining the Faulty RAM Card 4-15 Running System Verification Tests 4-16 Dealing with HPMC (Uncorrectable Error) 4-18 HPMC Caused by a Data Cache Parity Error 4-22 HPMC Caused by a Multi-Bit Memory Parity Error 4-23 Interpreting the Table 4-23 Determining the Faulty Memory Card 4-24 Chassis Test Codes 4-25...
  • Page 12 Contents Preliminary Procedures 5-7 Safety Precautions 5-8 Removing and Replacing the 743 Board Computer 5-9 Preliminary Requirements 5-9 Removal 5-9 Replacement 5-10 Replacing a 743 System Board 5-11 Preliminary Requirements 5-11 Removing and Replacing RAM Cards 5-13 Preliminary Requirements 5-13...
  • Page 13 Contents Removal 5-26 Replacement 5-27 Removing and Replacing the Front Panel Extension 5-28 Preliminary Requirements 5-28 Removal and Replacement 5-28 Removing and Replacing the Front Panel 5-30 Preliminary Requirements 5-30 Removal and Replacement 5-30 Socketed ICs 5-31 Preliminary Requirements 5-31 Removing and Replacing Socketed ICs 5-31 Removing and Replacing the Real-Time Clock Battery 5-33...
  • Page 14 PS/2 Connector 2-19 Power Distribution Diagram 2-28 Model 743 LED Location 4-8 Model 743 Board Computer Exploded View 5-4 Captive Screws: Single and Dual Slot 743 5-9 Retaining Screws and Standoffs 5-14 GSC Fasteners 5-16 Extension Adapter Fasteners 5-18 Removing the Labels and Springs 5-20...
  • Page 15 RAM Failure Chassis Codes vs. RAM Slot 2-24 Real-Time Clock Specifications 2-25 Interval Timer Specifications 2-26 Model 743 Board Computer Power Requirements 2-27 Main Menu Options 3-5 Paths for Booting and Human Interfaces 3-10 Mode Configuration - Control Flags 3-16...
  • Page 16 Contents Processor Module Error (Data Cache Parity) 4-22 Multi-Bit Memory Parity Error 4-23 Memory Address Ranges 4-24 Chassis Code Terms 4-26 Chassis Codes 4-27 Replaceable Parts 5-5 Reference Documentation 6-2...

  • Page 17: Product Information

    Product Information...

  • Page 18: Product Description

    Product Information Product Description Product Description The HP 9000 Model 743 is a high-performance Precision Architecture board computer based on the Hewlett-Packard PA-RISC 7100LC technology. It contains the following key features: • Model type: Model 743i/64 Model 743rt/64 Model 743i/100 Model 743rt/100 •...
  • Page 19 Product Information Product Description If the Model 743 is a client on a LAN, HP-UX can be booted over the LAN. HP-RT 2.0 and later. • User interface CDE or HP VUE graphical user interface (HP-UX only) • Compatibility Source and binary code compatible with Series 700 product family.
  • Page 20 (Dual slot means an expansion kit or HCRX board must be installed.) NOTE: A Model 743 configured for more than two RAM cards (one in each RAM stack) requires installation of an expansion kit or an HCRX graphics board and occupies two VME slots.
  • Page 21 PMC expansion board (with two PMC sites, requires PMC bridge) ATM Network Card (up to 2, GSC expansion kit required, can- not be used with HCRX graphics) • Other Supported Configurations Hewlett Packard supports only products with HP approved parts, accessories, peripherals, operating systems, and applica- tion programs.

  • Page 22: Technical Information

    Technical Information Technical Information This section lists technical information for the Model 743. For official specifications, refer to the HP 9000 Series 700i/rt Technical Data Sheet for Models 743i/rt and 748i VMEbus Computer Systems. Electrical This section lists the electrical requirements for the Model 743. The following table shows the power requirements for a 743 without on-board graphics.

  • Page 23: Regulatory Compliances

    FCC 47 cfr. part 15 sub part J Class A; VCCI Class A; Certification EN55022/CISPR22 Class A; Australia C-Tick AS/NZS 2064.1/2:1992 and AS/NZS 3548:1995 Environmental Requirements The following table shows the environmental requirements for the Model 743. Table 1-3 Environmental Requirements Temperature Operating: 0˚ to 55˚C;...

  • Page 24: Model 743 Vmebus Board Computer Temperatures

    Graphics Controller 101 Figure 1-1 Model 743 VMEbus Board Computer Temperatures NOTE: The Model 743 should only be operated in an environment that is free from conductive pollution, including dry non-conductive pollution which could become conductive due to expected condensation.

  • Page 25: Hardware Support

    This section provides information on the hardware support for the Model 743. Field Repair Philosophy If a problem or failure occurs with the Model 743, the problem is diagnosed to the assem- bly having the failed part. That assembly is then replaced. In some cases, an assembly may be exchanged for rebuilt assembly.

  • Page 26: Supported Products

    Only products with Hewlett-Packard approved parts, accessories, periph- erals, operating systems, and application programs are supported by Hewlett-Packard. Any product with other than HP approved hardware or software connected or installed must have the non-HP approved hardware and software removed by the customer before On-Site repair is con- ducted.

  • Page 27: Accessory Cards

    Supported Products Accessory Cards The Model 743 supports the following accessory cards: • Memory; one or more of these RAM cards supported on both HP- UX and HP-RT operating systems: HP A4263A 8 Mbyte RAM Card HP A4264A 16 Mbyte RAM Card...

  • Page 28: Typical External Devices

    HP A4303A LAN; High-Density 15-Pin to 15-Pin AUI HP A4304A Video; High-Density 15-Pin to Standard 15-Pin F HP A4305A Video; High-Density 15-Pin to EVC connector HP A4167A Video; Standard 15-Pin M to EVC connector (for use with GSC graphics card and EVC monitor) • Standard cables: HP K2296 SCSI;...

  • Page 29: Keyboard And Mouse

    Product Information Supported Products Keyboard and Mouse The Model 743 supports the following: • HP A2840A Keyboard with mini-DIN connector • HP A2839A Mouse with mini-DIN connector 1-13...

  • Page 30: Repair Services

    Hewlett-Packard supports three types of repair services: • Return to Hewlett-Packard Repair - Customers can return the product to their local HP Sales and Service Office. An HP Bench Repair Engineer troubleshoots and repairs the hardware to the as- sembly level. The repair engineer may replace the defective assem- bly with a new or rebuilt assembly.

  • Page 31: Functional Description

    Functional Description...

  • Page 32: Overview

    • Boot ROMs • Graphics • Memory controller • VME interface • I/O controller, which controls the following interface circuits: Single-ended SCSI HP Parallel Audio RS-232 Figure 2-1 shows a top and front view of the Model 743 Board Computer.

  • Page 33: Model 743 Vmebus Board Computer

    Functional Description Overview Figure 2-1 Model 743 VMEbus Board Computer Top and Front View...

  • Page 34: Cpu Circuit

    Functional Description Overview CPU Circuit The HP PA-RISC 7100 CPU chip is located beneath the heat sink in the center of the board. Boot ROM Circuit The Boot ROM circuits: • Start the CPU functions • Self-test the board computer’s main circuits •...

  • Page 35: System Failure Led

    Functional Description Overview System Failure LED This red LED turns on momentarily when power-up functions occur. It goes out after the board computer finds the VMEbus services as the operating system boots. During normal operation, should VMEbus services fail, the system fail LED turns on. Power LED A green LED indicates either a failure or functional mode, depending on the on-off rate.

  • Page 36: Graphics Circuit

    Functional Description Overview Graphics Circuit System boards with on-board graphics circuit have the display RAM and can be config- ured for several types of monitors. Graphic monitors connect to the 15-pin video connec- tor. Figure 2-2 shows the video connector, and Table 2-2 shows the video connector pinouts.

  • Page 37: Keyboard

    Double-bit errors are detected but not corrected. Tri- ple and quadruple bit errors are grouped in nybbles, using a 64-bit memory bus. The Model 743 uses two RAM card locations. RAM stacks are labeled on the system board as: •...

  • Page 38: Memory Map

    Functional Description Overview Memory Map Table 2-3 shows the Main Memory Map for the Model 743. Table 2-3 Main Memory map High Size Chip Description Address Address F000 0000 F01F FFFF I/O ASIC I/O ASIC #1 space F020 0000 F020 7FFF...
  • Page 39 Functional Description Overview Table 2-3 Main Memory map High Size Chip Description Address Address FFC2 0000 FFDF FFFF Unused FFE0 0000 FFE0 7FFF EISA EISA ASIC; GSC+ mode ASIC FFE0 8000 FFF7 FFFF 1504K Unused FFF8 0000 FFF8 3FFF I/O Flex Module 0 FFF8 4000 FFF8 7FFF PCI ASIC #1 registers...

  • Page 40: I/O Controller Asic

    Functional Description Overview I/O Controller ASIC The Model 743 uses an I/O Controller ASIC to control the input and output of the follow- ing: • Audio • Speaker • HP Parallel • RS-232 Port A • AUI LAN • SCSI •...

  • Page 41: Built-In Interfaces

    The following sections provide more information on the function of each interface. Audio Model 743 board computers provide compact disc-quality audio input and output in stereo with a 16-bit coder-decoder (CODEC) over a frequency range of 25-20,000 Hz. Output is provided by a small internal speaker and a stereo headphone mini-plug (8 Ohms imped- ance).

  • Page 42: Audio Connector

    Functional Description Built-in Interfaces Table 2-5 Audio Interface Specifications Stereo Line Input Mono microphone input Stereo Line Out Mono speaker output Crystal CS4215 or Analog Devices AD1849 CODEC Up to 48 KHz Sampling rate Figure 2-3 Audio Connector Table 2-6 Audio Connector Pinouts Pin No.

  • Page 43: Hp Parallel

    The Series 700 Scanjet interfaces are not supported. A high density micro D-sub connector is used for the HP Parallel interface. An HP A4300A conversion cable is required to convert to standard PC compatible 25-pin female D-sub.

  • Page 44: Rs-232 Ports

    National 16550 serial interface chip. Serial Port B is not functional until VME Services software is loaded and operating. The serial ports use a high density connector. An HP A4301A conversion cable is required to convert it to a standard PC compatible, 9 pin male D-sub. The maximum baud rate listed is the hardware limit.

  • Page 45: Rs-232 Serial Connector

    Functional Description Built-in Interfaces Table 2-9 RS-232-C Specifications Odd, even, none. one, zero Parity: 1, 1.5, 2 Stop bits: 9-pin female micro D-sub Connector Type: 16550 UART compatible megacell Controller: Figure 2-5 shows the RS-232 serial connector. Figure 2-5 RS-232 Serial Connector Table 2-10 shows the RS-232-C connector pinouts.

  • Page 46: Aui Lan

    Functional Description Built-in Interfaces AUI LAN LAN circuits use the Ethernet/IEEE 802.3 standard interface. Only the Attachment Unit Interface (AUI) version is used; no BNC connector is provided for ThinLAN. The shared memory area has the memory controller circuits, 16 Kbytes of RAM, 64 nybbles of non- volatile storage of the node address, and control, status, and ID registers.

  • Page 47: Scsi

    Functional Description Built-in Interfaces SCSI The built-in SCSI-2 port is implemented using an NCR710 macrocell inside the I/O ASIC chip. This 8-bit single ended implementation is compatible with the current Series 700 products and supports 5 Mbytes/sec data transfer rates. The SCSI bus is terminated to 3.3 volts through 127 Ohms.

  • Page 48: Scsi Connector Pinouts

    Functional Description Built-in Interfaces Table 2-13 shows the SCSI connector pinouts. Table 2-13 SCSI Connector Pinouts Signal Signal Signal Number Number Number DATA 0 DATA DATA 2 DATA 3 DATA 4 DATA 5 DATA 6 DATA 7 Data Parity 2-18...

  • Page 49: Ps/2 Ports 1 And 0

    Functional Description Built-in Interfaces PS/2 Ports 1 and 0 There are two PS/2 style serial ports: one PS/2 keyboard port and one PS/2 mouse port. In the Boot Console Handler’s hardware menu and on the front panel, they are listed as PS/2-0 (Kbd) and PS/2-1. Figure 2-8 shows the PS/2 connector. Figure 2-8 PS/2 Connector Table 2-14 shows the PS/2 connector pinouts.

  • Page 50: Vme Controller Asic

    Functional Description Built-in Interfaces VME Controller ASIC A VME controller ASIC manages the board computer’s interface with the VMEbus back- plane it plugs into. In addition, the RS-232 interfaces are also controlled by the VME con- troller ASIC. Table 2-15 and Table 2-16 list the VMEbus connector pinout information. Table 2-15 VME P1/J1 Pin Assignments and Signal Mnemonics Pin Number...

  • Page 51: Vme P2/J2 Pin Assignments & Signal Mnemonics

    Functional Description Built-in Interfaces Table 2-15 VME P1/J1 Pin Assignments and Signal Mnemonics Pin Number Row A Row B Row C IACK GROUND IACKIN SERCLK(1) IACKOUT SERDAT(1) GROUND IRQ7 IRQ6 IRQ5 IRQ4 IRQ3 IRQ2 IRQ1 -12 Vdc +5 V STDBY +12 Vdc +5 Vdc +5 Vdc...
  • Page 52 Functional Description Built-in Interfaces Table 2-16 VME P2/J2 Pin Assignments and Signal Mnemonics Pin Number Row A Row B Row C User Defined User Defined User Defined User Defined User Defined User Defined User Defined Ground User Defined User Defined +5 Vdc User Defined User Defined...

  • Page 53: Graphics Accessory Cards

    Graphics Accessory Cards Graphics Accessory Cards Graphics accessory cards have the same circuits as on-board graphics. Graphics cards supported on HP-UX and HP-RT operating systems include the HP A4267A 8-Plane Color Graphics Card, the HCRX8/VME, and the HCRX24/VME graph- ics cards.

  • Page 54: Ram Cards

    Functional Description RAM Cards RAM Cards RAM cards supported on both HP-UX and HP-RT operating systems include: • HP A4263A 8 Mbyte RAM Card • HP A4264A 16 Mbyte RAM Card • HP A4265A 32 Mbyte RAM Card • HP A4266A 64 Mbyte RAM Card RAM cards may be installed in any order.
  • Page 55 Battery Backed Real-Time Clock Battery Backed Real-Time Clock The Model 743 uses a battery backed read-time clock. This section provides safety infor- mation for handling lithium batteries. This section also provides information on the timers used in the Model 743.

  • Page 56: Interval Timers

    Functional Description Battery Backed Real-Time Clock Interval Timers The VME Controller ASIC includes two interval timers and a watchdog timer. These tim- ers provide interrupt on terminal count and interrupt and restart on terminal count capabil- ity. Table 2-20 lists the interval timer specifications. Table 2-20 Interval Timer Specifications Timer 1 Length...

  • Page 57: Power Distribution

    Functional Description Power Distribution Power Distribution Power is distributed through the VMEbus chassis’ P1 and P2 connectors to the Model 743 board computers PC boards: • System board and RAM card power comes through the system board’s P1 and P2 connectors.

  • Page 58: Power Distribution Diagram

    Functional Description Power Distribution Figure 2-9 Power Distribution Diagram 2-28...

  • Page 59: Configuration

    Configuration...

  • Page 60: Introduction

    Configuration Introduction Introduction This chapter provides detailed information on the various types of configurations available for the Model 743 board computer. This chapter provides step-by-step instructions for using the Boot Console handler, and information about graphics configuration.

  • Page 61: Boot Console Handler

    Configuration Boot Console Handler Boot Console Handler This section presents configuration capabilities of the Boot ROM, including: Using the Boot Console Handler Configuration Modes Overview of the Boot Console Handler The Boot ROM contains a micro-operating system called the Boot Console Handler (BCH).

  • Page 62: Using The Boot Console Handler

    Configuration Using the Boot Console Handler Using the Boot Console Handler Perform the following steps to enter and use the boot console user interface: Shut down your application. Press the Rst/Abt switch on the front panel to the Rst (reset) position. The system pauses, resets, then displays a screen similar to: PDC - Processor Dependent Code - Version 300.0 release 0 (c) Copyright 1994, Hewlett-Packard Company, All rights...

  • Page 63: Main Menu Options

    Configuration Main Menu Main Menu The Main Menu is the first menu in the menu hierarchy. To select an item from the Main Menu, enter the associated key number and press Enter. For example, if you want to select Boot From a Device from the Main Menu, type: Enter ==== MAIN MENU =============================== Operation...

  • Page 64: Main Menu

    Configuration Main Menu Table 3-1 Main Menu Options Operation Description Mode Configuration The underlying menus lets you select a mode (see modes below) for use or to change and save any of a mode’s attributes. Interactive Testing This menu item lets you execute individual optional tests or enter the debug environment.

  • Page 65: Boot From A Device Menu

    Configuration Boot From a Device Menu Boot From a Device Menu Access the Boot From a Device menu by entering the following from the Main Menu: Enter When you invoke the Boot From a Device menu item, the system displays a list of boot device categories.
  • Page 66 Configuration Boot From a Device Menu Scanning for Boot devices. Please wait... ==== BOOT FROM DEVICE ======================== Boot Device ----------------------------------------- SCSI.6.0 QUANTUM FIREBALL1050S SCSI.5.0 QUANTUM FIREBALL1050S LAN.15.20.93.16 INSTALL 15.20.93.16 LAN.15.20.88.47 INSTALL 15.20.88.47 LAN.15.20.88.100 INSTALL 15.20.88.100 LAN.15.20.88.96 INSTALL 15.20.88.96 LAN.15.20.92.249 INSTALL fibula .........

  • Page 67: Path Configuration Menu

    Configuration Path Configuration Menu Path Configuration Menu The Primary and Alternate Path menus also performs a search for bootable devices. To access the Path Configuration menu, enter the following from the Main Menu: Enter The system displays the Path Configuration menu, as shown: ==== PATH CONFIGURATION ====================== PRIMARY PATH now [ SCSI.6.0 ]...

  • Page 68: Primary Or Alternate Path Menus

    Configuration Path Configuration Menu Table 3-2 Paths for Booting and Human Interfaces Path Name Name Primary Path A bootable device Alternate Path A bootable device Console Path A graphics monitor or RS-232 interface KEYBOARD PATH A keyboard interface Interfaces used for booting, such as SCSI or LAN may have multiple devices attached. If you plan to consistently boot your system from a specific device, you should choose that device as the Primary Path.

  • Page 69: Keyboard Path Menu

    Configuration Path Configuration Menu If you choose an RS-232 device, a new menu appears, allowing you to set various func- tional attributes such as baud rate. For graphics interfaces which can support multiple monitor types, a new menu appears prompting you to select the correct monitor type you have connected to the system. The bottom section of the menu allows you to: •...

  • Page 70: Mode Configuration Menu

    A list of optional selftests to execute • A set of control flags The values of all these attributes are stored in the 743’s EEPROMs. To access the Mode Configuration menu, enter the following from the Main Menu: Enter The system displays the...

  • Page 71: Setting Values In The Mode Configuration Menu

    Configuration Mode Configuration Menu Config (Emergency) Mode A feature in the Boot ROM called Config Mode or Emergency Mode is invoked by holding the Rst/Abt switch in the `Abt’ (abort) position when the power is turned on. There is no EEPROM storage associated with this mode.

  • Page 72: Mode Configuration Menu Selections

    Configuration Mode Configuration Menu The bottom section of the menu allows a user to: • Return to the previous menu • Set the attribute values to the factory default values for the current mode • Reset the system • Change the current mode If any attribute values have been changed since this menu was entered, the bottom section will only allow a user to: •...

  • Page 73: Console Search Control

    Configuration Mode Configuration Menu Console Search Control The Console Search Control menu is split into two lists. The top section lists paths and interfaces the Boot ROM uses to locate a console device. The names appear in the order in which they will be used.

  • Page 74: Control Flags

    YES means that optional self-tests will not be executed and that tests on some interfaces and devices such as graphics will be min- imized. Because HP-UX requires that console and all graphics devices be initialized before control is given to the OS, it is strongly recommended that Fast Boot be left at NO.
  • Page 75 Configuration Mode Configuration Menu Table 3-3 Mode Configuration - Control Flags Control Setting Indications Repeat Scan for YES means that if the attempt to locate a boot device fails, start at Auto Boot the beginning of the search list and try again. This process will devices continue indefinitely.

  • Page 76: Interactive Testing

    GRAPHICS 3 INIT GRAPHICS 4 INIT ......... Previous Menu Enter Debug Environment Reset the System --------------------------------------------- To run a test, Press Key, then press [Enter/Return] Table 3-4 provides a description for the types of interactive tests available on the Model 743. 3-18...

  • Page 77: Interactive Testing Limitations

    HIL INIT Initializes and tests the HIL interface. This test supports the Model 748i VME system’s HP-HIL connector used with its EISA converter board. If no HIL device is connected, the test reports FAILED. If an HIL device is connected and is not the Console device, the test reports PASSED.
  • Page 78 Configuration Interactive Testing GRAPHICS 1 interactive test. The test will not be run on that graphics sub- system. That sub-system was tested at console selection time and if it is work- ing, it will not be tested. If the device is not physically present, the test will report “hardware not present.”...

  • Page 79: Accessing Firmware Information

    Configuration Accessing Firmware Information Accessing Firmware Information This menu shows: The revision number of the PDC version. The revision numbers of the main hardware ROMs. The revision numbers of the extension ROMs This data on this menu gives an indication of what capabilities are present and what I/O interfaces the firmware can work with.
  • Page 80 CPU Memory-I.O Controller ROM in CPU MSGS (Eng) Language ROM EISA EISA Controller RS-232 Serial ROM SCSI SCSI ROM HP-HIL ROM FW SCSI FWSCSI ROM PCI Tray ROM PMC Bridge/Expander ROM GSC Expansion Card ROM PCMCIA ATA PCMCIA ROM Backplane ROM 3-22...

  • Page 81: Hardware Information

    To access the Hardware Information menu, enter the following from the Main Menu: Enter The system displays the Hardware Information menu, as shown: ==== HARDWARE INFORMATION ==================== Computer Model 9000/743 System Board Serial No. 40SM9J0259 Cache Size 128 Kbytes 128 Kbytes Component...
  • Page 82 Configuration Hardware Information The bottom section of the menu allows you to: • Return to the previous menu • Reset the system 3-24...

  • Page 83: Asic Hardware Component Information

    To view the I/O ASIC Hardware Component menu, enter the following from the Hardware Information menu: Enter The system displays the Hardware Component Info screen, as shown: ==== HARDWARE COMPONENT INFO ================= I/O ASIC AUDIO HP PARALLEL RS-232 (A) LAN 080009-8C8641 SCSI PS/2 (0) PS/2 (1) Operation .........

  • Page 84: Graphics Information

    Configuration ASIC Hardware Component Information Graphics Information The Hardware Information menu shows the locations of the graphics hardware, indicated by GRAPHICS 1, 2, and 3. The identifying number may changed depending on the sys- tem board type and graphics accessory cards installed. (see: Graphics Configuration in this chapter.) 3-26...

  • Page 85: System Configuration Menu

    WARNING: Use this menu for BPN and BPR support ONLY after you have consulted with HP Support Services The only HP supplied entries here are BPN (Back Plane Networking) Configuration and BPR (Backplane ROM) Configuration. ==== SYSTEM CONFIGURATION ==================== Operation...
  • Page 86 Configuration System Configuration Menu Typing 2 Enter at the SYSTEM CONFIGURATION MENU puts the following BPR submenu on the screen: Current BPR configuration: VME address = 0x00000000 AM code = 0x00 values example: 0x12345678 0x0d Type value(s), then press [Enter/Return] The general sequence of operations in this menu is: Type in the data (VME address, AM Code) as one line, as indicated by the "value ex- ample"...

  • Page 87: Graphics Configuration

    Graphics Configuration Graphics Configuration System boards may or may not have on-board graphics. If your Model 743 does not have a graphics card, and the customer wants to run an application that requires graphics, either a 743 board computer with on-board graphics installed must be ordered to replace the origi- nal board, or graphics capability must be added to the system through the installation of the Expansion Kit or an HCRX graphics board.
  • Page 88 HCRX board, GRAPHICS 2 HCRX board and HP HCRX board, GRAPHICS 1 A4267A card (no on- HP A4267A card, GRAPHICS 2 board graphics) HCRX board and HP On-board graphics, GRAPHICS 1 A4267A card and on- HCRX board, GRAPHICS 2...
  • Page 89 Configuration Graphics Configuration ==== CONSOLE PATH ============================ CONSOLE PATH now [ GRAPHICS 1 ] Device Path ----------------------------------------- GRAPHICS 1 RS-232 (A) Null Device RS-232 (B) ......... Previous Menu Rescan for console devices Reset the System ---------------------------------------------- To set the CONSOLE PATH, Press Key, then press [Enter/Return] The Console Path menu lists the graphics as GRAPHICS 1, GRAPHICS 2, etc., up to the number installed in the system.
  • Page 90 Configuration Graphics Configuration Enter the number for the desired graphics configuration. Enter the following to save the changes and return to the previous menu: Enter 3-32...

  • Page 91: Troubleshooting

    Troubleshooting...

  • Page 92: Introduction To Troubleshooting

    Field Replaceable Unit(FRU) and the FRU is replaced to correct a problem. To troubleshoot a 743 you must be familiar with the HP-UX operating system and be able to start and stop processes. You should familiarize yourself with the various diagnostic software available and understand what the test results indicate.

  • Page 93: Isl Environment

    Troubleshooting Introduction to Troubleshooting ISL Environment ISL provides the means to load the operating system. ISL also provides an offline platform to execute diagnostic and utility programs contained in the LIF volume on the boot device when the operating system is not loaded. The ISL program is the first program loaded into main memory from an external media (LAN, disk, or tape) and launched by the initial program loader (IPL) routine from the Boot Administration environment.

  • Page 94: Boot Rom Selftests

    Troubleshooting Boot ROM Selftests Boot ROM Selftests Selftests are called by a bootstrap program resident in the Boot ROM. The Selftests initial- ize and test the board computer hardware needed to find and boot an operating system. I/O portions for the console and boot path are tested by the I/O Dependent Code (IODC) for each I/O function.

  • Page 95: Hardware Initialization Support

    Troubleshooting Boot ROM Selftests Hardware Initialization Support Some hardware, such as video circuit initialization and floating RAM positioning, which can not wait for a system to be booted, must be initialized at power-up as soon as possible to prevent improper operation. Go/No-Go Selftest Support The primary objective is to tell the user that the board computer can boot the operating system.

  • Page 96: Early Selftest

    Extended Selftest The purpose of the extended Selftest is to test those areas of the board computer which are not routinely tested by the power-up Selftest. This includes VMEbus, HP-IB, the real-time clock and timers. The Boot Console User Interface is used to configure operation of the extended Selftest.
  • Page 97 Troubleshooting Boot ROM Selftests The extended Selftest tests these devices: Time of day clock (RTC) The three timers RS-232 ports A & B SCSI Graphics, if installed HP-HIL HP-IB VMEbus HP Parallel...

  • Page 98: Firmware Selftest Failures

    RS-232 (A) port. Interpreting the Front Panel LEDs The Model 743 provides two LEDs, located to the left and right of the reset switch, as shown in Figure 4-1. The red LED is labeled SYSFAIL and the green LED is labeled POWER.

  • Page 99: Led Indicators

    Troubleshooting Firmware Selftest Failures Table 4-1 provides information on interpreting the system status from the LEDs. Table 4-1 LED Indicators SYSFAIL POWER Meaning Possible Solution (Red) (Green) No Power Check for board seating in chassis. 2Hz Flash Normal Power-on/ If the system never proceeds selftest past this point, either the con- sole path is not set or there is...

  • Page 100: Boot Options

    Troubleshooting Boot Options Boot Options If the usual boot device (typically a disk) is not responding as it should, you must attempt to boot from the disk (or another boot device) by selecting it manually. You may also want to access the ISL or Interactive Testing capabilities of the system. To access boot options, follow these steps: Power off your board computer for a few seconds.
  • Page 101 Troubleshooting Boot Options From the Main Menu, enter the following to select Boot From a Device: 1 Enter When you invoke the Boot From a Device menu item, the system displays a list of boot device categories. Which of these categories can actually be booted from depends on the system configuration: ==== BOOT DEVICE SELECT ====================== PRIMARY PATH...
  • Page 102 Troubleshooting Boot Options Scanning for Boot devices. Please wait... ==== BOOT FROM DEVICE ======================== Boot Device ----------------------------------------- SCSI.6.0 QUANTUM FIREBALL1050S SCSI.5.0 QUANTUM FIREBALL1050S LAN.15.20.93.16 INSTALL 15.20.93.16 LAN.15.20.88.47 INSTALL 15.20.88.47 LAN.15.20.88.100 INSTALL 15.20.88.100 LAN.15.20.88.96 INSTALL 15.20.88.96 LAN.15.20.92.249 INSTALL fibula ......... Previous Menu Effective ISL Mode [ AUTOMATIC ] Rescan for Boot devices...

  • Page 103: Interactive Testing Menu

    Tests the CPU super scalar operations HIL INIT Initializes and tests the HIL interface. This test support the Model 748i VME system’s HP-HIL connector used with its EISA converter board. If this is the console keyboard, the test will not run, but will report “passed”.

  • Page 104: Running Ode-Based Diagnostics

    Troubleshooting Running ODE-Based Diagnostics Running ODE-Based Diagnostics The Offline Diagnostic Environment (ODE) consists of diagnostic modules for testing and verifying system operation. ODE provides all the necessary functions for the user to load specified tests and interact with those tests. ODE is an ISL utility.

  • Page 105: Determining The Faulty Ram Card

    Troubleshooting Determining the Faulty RAM Card Determining the Faulty RAM Card If a memory failure is detected during memtest execution, the failing memory card is indi- cated. The following lists shows the location of the RAM stacks: • RAM stack 1 is located behind the two PS/2 connectors on the board computer’s right side.

  • Page 106: Running System Verification Tests

    Running System Verification Tests Running System Verification Tests HP-UX uses an online diagnostics product called the Support Tools Manager that allows system operation verification. HP-RT does not support online diagnostics. Three interfaces are available with the Support Tools Manager: a command line interface (accessed through the cstm command), a menu-driven interface (accessed through the mstm command), and the graphical user interface (accessed through the xstm command).
  • Page 107 Troubleshooting Running System Verification Tests To access the Support Tools Manager, you must be logged in as “root” or “superuser”, and perform the following steps: In a terminal window, type the following at the # prompt to invoke the command line interface: # cstm The following message appears:...

  • Page 108: Dealing With Hpmc (Uncorrectable Error)

    Troubleshooting Dealing with HPMC (Uncorrectable Error) Dealing with HPMC (Uncorrectable Error) The power-on sequence follows this path: Power-on -> Selftest -> Console Path -> Boot Admin Mode -> Boot Path -> ISL Mode -> Operating System Mode When the hardware detects an unrecoverable (HPMC) error in the Operating System envi- ronment, an error message, referred to as a Kernel Tombstone is displayed on the monitor.

  • Page 109: Pim Action Table

    Troubleshooting Dealing with HPMC (Uncorrectable Error) To identify the failed FRU(s) after an HPMC, follow these steps: Examine the “Other Processor Data” words returned from the PIM command to display the latest error information from the last TOC, LPMC, or HPMC interruption detected.
  • Page 110 Troubleshooting Dealing with HPMC (Uncorrectable Error) Table 4-4 PIM Action Table Cache System Check Bus Check Check Responder Action Type Word Word Word Word 0x20000000 0x00310007 0xF4000000 Replace Graphics in 0xF5FFFFFF GSC Slot 2, if present, otherwise check VME cards, and/or replace CPU board.
  • Page 111 Troubleshooting Dealing with HPMC (Uncorrectable Error) Table 4-4 PIM Action Table Cache System Check Bus Check Check Responder Action Type Word Word Word Word 0x20000000 0x00310007 0xFFF88000 Replace optional 0xFFF8BFFF GSC card in GSC Slot 2, if present, or replace CPU board. 0x20000000 0x00310007 0xFFF8C000F...

  • Page 112: Hpmc Caused By A Data Cache Parity Error

    Troubleshooting Dealing with HPMC (Uncorrectable Error) HPMC Caused by a Data Cache Parity Error For example, an HPMC interruption is forced when a data cache parity error is detected during a load instruction to the memory address space or during a data cache flush opera- tion.

  • Page 113: Hpmc Caused By A Multi-Bit Memory Parity Error

    Troubleshooting Dealing with HPMC (Uncorrectable Error) HPMC Caused by a Multi-Bit Memory Parity Error An HPMC interruption is forced when a multi-bit memory parity error is detected during a “DMA read” operation or fetching an I/D cache line (32 bytes). Table 4-6 shows an example of the HPMC error information retrieved from Stable Storage by the PIM command from the Interactive Testing Debug Environment.

  • Page 114: Determining The Faulty Memory Card

    0x00000000 to a maximum of 0x0FFFFFFF (256MB). Memory is installed on the Model 743 in two stacks of up to four memory cards of 8MB, 16MB, 32MB, or 64MB capacity. The card on the bottom of Stack 1 is considered to be in physical slot 0, the second board in Stack 1 is physical slot 1, the third card is physical slot 2, and the card in Stack 2 is physical slot 4.

  • Page 115: Chassis Test Codes

    Troubleshooting Chassis Test Codes Chassis Test Codes This section provides information on interpreting chassis codes. It also provides a table which you can use to reference the chassis codes and the associated troubleshooting actions. Introduction Hexadecimal numbers are displayed during start up and other tests. These numbers repre- sent tests and failures occurring in the board computer.

  • Page 116: Chassis Code Terms

    If the chassis code indicates a normal function or test, but the board computer is not continuing on with its process, the assembly listed in the `Replace’ column should be replaced. Replace the Model 743 system board to repair the board computer. Chassis Code Terms Table 4-8 shows the abbreviations used in the chassis codes.

  • Page 117: Chassis Codes

    Troubleshooting Chassis Test Codes Table 4-9 lists the chassis codes, the function, test, or error associated with the code, and solution. Table 4-9 Chassis Codes 0x Code Function, Test, or Error Replace: 10000 Blank the display System board 20000 RAM errors RAM card 21000 Unexpected interrupt occurred during PDC...
  • Page 118 Troubleshooting Chassis Test Codes Table 4-9 Chassis Codes 0x Code Function, Test, or Error Replace: 27104 RAM error; physical slot 4 Slot 3 RAM card 2C5F0 Primary IPL fatal fault System board 2CBF0 HPMC handling initiated System board 2CBFB Branching to operating system HPMC handler System board 2CBFF Nested HPMC occurred (hanging the...
  • Page 119 Troubleshooting Chassis Test Codes Table 4-9 Chassis Codes 0x Code Function, Test, or Error Replace: 41095 Hardware TLB test System board 41096 DTLB trap System board 410D0 MIOC diagnostic System board 410D1 MIOC interrupts System board 410D2 MIOC HPMC System board 410D3 MIOC transfer of control System board...
  • Page 120 Troubleshooting Chassis Test Codes Table 4-9 Chassis Codes 0x Code Function, Test, or Error Replace: 42098 Cache byte System board 42099 I-cache miss System board 4209A D-cache miss System board 4209B Cache done System board 4209F U-cache RAM System board 43000 Start ROM checksum Selftest System board...
  • Page 121 Troubleshooting Chassis Test Codes Table 4-9 Chassis Codes 0x Code Function, Test, or Error Replace: 48326 Built-n HP Parallel System board 48328 Built-in Audio System board 4832B Built-in PS/2 Port 0 (keyboard) System board 4832C Built-in PS/2 Port 1(mouse) System board...
  • Page 122 Troubleshooting Chassis Test Codes Table 4-9 Chassis Codes 0x Code Function, Test, or Error Replace: 6C2EB Checking slots for EISA cards System board or Model 748’s EISA controller or back- plane 6C2EC No configuration data for card in this slot Card in Model 748’s EISA slot 6C2ED...
  • Page 123 Troubleshooting Chassis Test Codes Table 4-9 Chassis Codes 0x Code Function, Test, or Error Replace: 6C5F2 Bad LIF magic primary System board 6C5F3 Bad IPL primary size System board 6C5F4 Bad IPL entry primary System board 6C5F8 Bad IPL checksum primary System board 6C5FF Branching to IPL...
  • Page 124 Troubleshooting Chassis Test Codes Table 4-9 Chassis Codes 0x Code Function, Test, or Error Replace: A3002 Error occurred writing to EEPROM System board CCA00 Power fail recover System board 4-34...

  • Page 125: Field Replaceable Units

    Field Replaceable Units...

  • Page 126: Introduction

    Introduction Introduction This chapter lists the field replaceable parts for the HP 9000 Series 700i/rt Model 743i/rt VMEbus Board Computers. Components, including most of the ICs, are not available for field repair. The chapter includes information on the tools required to replace assemblies and safety precautions you should follow when replacing assemblies.

  • Page 127: Local Office Information

    Field Replaceable Units Introduction Europe Support Materials Organization Support material & Services Europe Hewlett-Packard Company Hewlett-Packard Ltd. 8050 Foothills Boulevard Filton Road - Stoke Gifford Roseville, CA 95678 USA Bristol BS12 6QZ United Kingdom Telephone: (916) 786-8000 Telephone: +44 272 799910 Local Office Information Use the following section to make note of your local Hewlett-Packard sales and service office for future reference.

  • Page 128: Replaceable Parts

    Field Replaceable Units Replaceable Parts Replaceable Parts Figure 5-1 highlights the major pieces of the Model 743 assembly, and Table 5-1lists the part numbers of the Model 743 replaceable parts. Figure 5-1 Model 743 Board Computer Exploded View...

  • Page 129: Replaceable Parts

    Field Replaceable Units Replaceable Parts Table 5-1 Replaceable Parts Callout Exchange Description Number Part Number Part Number System board: 64 MHz (without on-board graphics) A2636-69401 A2636-66001 System board: 64 MHz (with on- board graphics) A2636-69413 A2636-66013 System board: 100 MHz (without on-board graphics) A2636-69415 A2636-66015...
  • Page 130 A4500-62009 WARNING: Replace battery only with Matsushita Electric BR-1616 three-volt lithium battery (HP part number 1420-0525)! Using any other battery can cause fire or explosion. Lithium batteries can explode if mistreated. Do not put lithium batteries in fires, try to recharge or...

  • Page 131: Tools Required And Preliminary Procedures

    Field Replaceable Units Tools Required and Preliminary Procedures Tools Required and Preliminary Procedures Tools Required for Assembly/Disassembly All field replaceable parts can be accessed with these tools: Grounding wrist strap and static-free work place No. 1 Pozidriv screwdriver Small flat-tipped screwdriver 3mm (0.125-in.) thin-wall nutdriver, maximum outer diameter of 5.7mm (0.225-in.).

  • Page 132: Safety Precautions

    Field Replaceable Units Safety Precautions Safety Precautions It is essential to practice safety precautions when working with any electrical or electronic products. Following these safety precautions can help protect both you and the equipment from injury and possible permanent damage. Whether the ICs are installed on a printed circuit board or laying on a table, integrated cir- cuit components can be damaged by electro-static discharge.

  • Page 133: Removing And Replacing The 743 Board Computer

    Removing and Replacing the 743 Board Computer This section provides step-by-step instructions for removal and replacement of a single VME slot and dual VME slot 743 board computer. Preliminary Requirements Perform the following procedure before you remove the board computer from its VMEbus chassis: Perform the steps in the Preliminary Procedures section of this chapter.

  • Page 134: Replacement

    Field Replaceable Units Removing and Replacing the 743 Board Computer Replacement Loosen the captive screws (labeled 1 and 2, 3 and 4, in Figure 5-2) at each end of the board computer and the Extension panel. Raise both ejector levers outwards and pull the board computer and extension out of the VMEbus chassis.

  • Page 135: Replacing A 743 System Board

    This section provides step-by-step instructions for replacing a system board. NOTE: If your 743 is configured as a dual VME slot computer, once the accessory boards, cards, any stacked RAM and Front Panel extension are removed the computer is in effect a single slot computer and can be dealt with as such for work on EEPROMs, PCMCIA (743rt only) and single RAM cards.
  • Page 136 After removing all the accessories, place them on the new/exchange board and send in the failed board. Reinstall the 743 in it’s chassis. (Removing and Replacing the 743 Board Computer.) CAUTION: When installing additional cards or replacing the CPU, always use the latest version BootROM available.

  • Page 137: Removing And Replacing Ram Cards

    743. Preliminary Requirements Perform the following step before you remove a RAM card: Remove the 743 from it’s chassis. (Removing and Replacing the 743 Board Computer) WARNING: Be aware that older RAM cards (EDC# A-0201-SM) require gold colored spacers/standoffs under them.

  • Page 138: Removal

    Field Replaceable Units Removing and Replacing RAM Cards Removal Follow these steps to remove RAM cards: Remove the retaining screws from the uppermost RAM card as shown in Figure 5-3. Figure 5-3 Retaining Screws and Standoffs 2 Pull the RAM card up and off the RAM stack or board computer. 3 Repeat the procedure for multiple RAM cards.

  • Page 139: Removing And Replacing Gsc Cards

    Removal Follow these steps to remove a GSC card: Working from the back of the Model 743 Board Computer, the GSC graphics cards are in either the right-hand or center position shown in Figure 5-4. Remove the two M2.5X5 screws that hold the card to the front panel extension plate.

  • Page 140: Replacement

    Field Replaceable Units Removing and Replacing GSC Cards Fixture screws M2.5X5 & positions Screw panel locations Figure 5-4 GSC Fasteners Remove the two M2.5X6 screws which hold the GSC card to the adapter (Expansion Kit) fixture. Remove the card by lifting it upwards out of the GSC connector. Replacement To replace the graphics card, reverse the steps in the procedure for removing a graphics card.

  • Page 141: Removing And Replacing The Gsc Adapter

    Perform the following steps before removing the GSC adapter (Expansion Kit) from your Model 743: Remove the 743 from it’s chassis. (Removing and Replacing the 743 Board Computer, page 5-9 .) Remove any GSC cards. (Removing and Replacing GSC Graphics/FWD SCSI cards.)

  • Page 142: Extension Adapter Fasteners

    Field Replaceable Units Removing and Replacing the GSC Adapter M2.5X12 screws M2.5X6 screws Figure 5-5 Extension Adapter Fasteners Remove the four DIN connector M2.5X12 screws from the bottom of the system board. Remove the adapter assembly from the system board by lifting straight up and disen- gaging it from the centered connector.

  • Page 143: Removing And Replacing The Pmc Adapters

    fixture in your Model 743. Preliminary Requirements Before removing the adapter (Expansion Kit) fixture from your Model 743, remove the Model 743 from it’s card cage. (See Removing and Replacing the Model 743 Board Com- puter, earlier in this chapter.) Removal and Replacement Follow these steps to remove the adapters from your Model 743: Remove the ejector handle sleeve labels and springs, as shown in Figure 5-6.

  • Page 144: Removing The Labels And Springs

    Field Replaceable Units Removing and Replacing the PMC Adapters Ejector Handle Sleeves Figure 5-6 Removing the Labels and Springs 5-20...

  • Page 145: Removing The Sleeves

    Field Replaceable Units Removing and Replacing the PMC Adapters Figure 5-7 Removing the Sleeves 5-21...

  • Page 146: Removing The Pmc Expansion Adapter

    Field Replaceable Units Removing and Replacing the PMC Adapters Figure 5-8 Removing the PMC Expansion Adapter 5-22...

  • Page 147: Removing A Pmc Card From The Expansion Adapter

    Field Replaceable Units Removing and Replacing the PMC Adapters To remove a PMC card from the expansion adapter, remove the four screws from the bottom of the expansion adapter and separate the PMC card from the expansion adapt- er, as shown in Figure 5-9. Figure 5-9 Removing a PMC card from the Expansion Adapter 5-23...

  • Page 148: Removing The Pmc Bridge Adapter

    Field Replaceable Units Removing and Replacing the PMC Adapters Remove the bridge adapter’s four front panel screws, as shown in Figure 5-10. Remove the bridge adapter’s four VME connector screws, as shown in Figure 5-10. Separate the bridge adapter from the board computer. Figure 5-10 Removing the PMC Bridge Adapter 5-24...

  • Page 149: Removing A Pmc Card From The Bridge Adapter

    Field Replaceable Units Removing and Replacing the PMC Adapters Figure 5-11 Removing a PMC card from the Bridge Adapter 10 To remove a PMC card from the bridge adapter, remove the four screws from the bot- tom of the bridge adapter and separate the PMC card from the bridge adapter, as shown in Figure 5-11.

  • Page 150: Removing And Replacing An Hcrx Graphics Board

    An HCRX8 or HCRX24 Graphics board occupies the same position as the Expansion Kit adapter. These boards fasten to the 743 in almost the same way as the adapter, with four DIN screws and two M2.5X6 screws, however, there are an additional two small screws located on each side of the graphic’s connector that fasten through the front panel.

  • Page 151: Replacement

    Field Replaceable Units Removing and Replacing an HCRX Graphics Board Front Panel screws M2.5X6 screws M2.5X12 screws Figure 5-12 HCRX Board Fasteners Remove the four DIN connector M2.5X12 screws from the bottom of the system board. Remove the two small screws at each end of the graphic connector on the front panel. Remove the HCRX board from the computer by lifting it straight up from the centered connector.

  • Page 152: Removing And Replacing The Front Panel Extension

    Model 743. Preliminary Requirements Perform these steps before removing the front panel extension from the Model 743: Remove the 743. (Removing and Replacing the 743 Board Computer, page 5-9 .) Remove any GSC cards. (Removing and Replacing GSC Graphics cards.) Remove the Expansion adapter or HCRX board.
  • Page 153 Field Replaceable Units Removing and Replacing the Front Panel Extension NOTICE: To replace the front panel extension, reverse the steps for removing the front panel extension. 5-29...

  • Page 154: Removing And Replacing The Front Panel

    743. Preliminary Requirements Perform the following steps before removing the front panel: Remove the 743 from it’s chassis. Remove any GSC card connector screws. (Removing and Replacing GSC Graphics cards.) Remove the HCRX board (if installed) connector screws. (Removing HCRX board.) Remove the front panel extension.

  • Page 155: Socketed Ics

    Socketed ICs Socketed ICs This section provides step-by-step instructions for replacing the socketed integrated cir- cuits. You can replace the following socketed ICs in your Model 743, as shown in the accompa- nying figure: Boot ROM; U54 EEPROM; U55 OEM ROM; U52...

  • Page 156: Removable Ics

    Field Replaceable Units Socketed ICs EEPROM Figure 5-15 Removable ICs Use the IC removal tool to carefully grasp and remove the IC. 5-32...

  • Page 157: Removing And Replacing The Real-Time Clock Battery

    Do not try to recharge lithium batteries. Do not disassemble lithium batteries. Removal Perform the following steps before removing the RTC battery from your Model 743: Remove the 743 from it’s chassis. Remove any RAM or accessory cards installed at the board computer’s left position.

  • Page 158: Removing And Replacing The Pcmcia Adapter

    Perform the following steps before removing the PCMCIA adapter from your Model 743rt: Remove the 743rt from it’s chassis. (Removing and Replacing the 743 Board Comput- er, page 5-9 ) If an HCRX board or an Expansion kit adapter with a GSC card installed in the left slot is installed on the computer, remove them to the point where you can access the PCM- CIA adapter.

  • Page 159: Reference Documentation

    Reference Documentation...

  • Page 160: Reference Documentation

    Reference Documentation Introduction Introduction This chapter provides information on related documentation for the Model 743. The refer- ences include the manual name and part number. Table 6-1 Reference Documentation Manual Title Part Number Model 743 Owner’s Guide A2636-90606 HP-UX 9.05 VME Configuration and Driver Development Guide...
  • Page 161 Reference Documentation Introduction Table 6-1 Reference Documentation Manual Title Part Number PA-RISC Support Tools Manual Licensed Users Volume 7, Utili- 5960-3161 ties PA-RISC Support Tools Manual Licensed Users Volume 8, ISL 5960-3163 Support Tools PA-RISC Support Tools Manual HP Employees 5960-3165...
  • Page 162 Reference Documentation Introduction...
  • Page 163 Index conncetor Federal Communications Com- accessories, 1-11 video, 2-6 mission (FCC), iii accessory cards, 1-11 connector firmware air flow, 1-7 audio, 2-12 information, 3-21 altitude, 1-7 AUI LAN, 2-16 function, 2-7 audio, 2-11 parallel, 2-13 connector, 2-12 PS/2, 2-19 pinouts, 2-12 SCSI, 2-17 graphics, 2-6 AUI LAN, 2-16...
  • Page 164 Index operating systems, 1-2 regulations keyboard, 1-13, 2-7 options emissions, iii keyboard path, 3-11 graphics, 1-3 regulatory keyboard search control, 3-15 compliance, 1-7 Korean regulations, iv electromagnetic, 1-7 parallel, 2-13 FCC, iii connector, 2-13 safety, 1-7 LAN, 1-12, 2-16 pinouts, 2-14 statements, iii LAN ID, 2-4 part numbers, 5-5...
  • Page 165 Index supported products, 1-10 system configuration, 3-27 system verification tests running, 4-16 technical information, 1-6 temperature, 1-7 board, 1-8 testing interactive, 4-13 tests interactive, 3-19 running system verification, 4-16 timer watchdog, 2-26 timers interval, 2-26 tools, 5-7 upgrades, 1-4 3-slot, 1-5 dual slot, 1-4 user interface, 1-3 video...

This manual is also suitable for:

9000 series 743

Table of Contents
