S o A d v a n c e d . Y e t S o S i m p l e .
Your ProScan television is more than state-of-the-art
technology. It's technology tailored to you. Features
designed to deliver viewing and listening enjoyment
beyond expectations. Innovation and simplicity of
operation become one–ProScan.
Improving Your Image
• A Cleaner Picture: The Digital Comb Filter extends resolution
and minimizes color interference patterns for greater detail.
• No Glare™ Picture: Anti-Glare Lithium Silicate Faceplate
virtually eliminates glare while enhancing contrast.
• Increased Clarity: Up to 560 lines of horizontal resolution,*
surpassing the capabilities of all available signal sources.
* through S-VIDEO connector.
Sound Thinking
• 5 Watts Per Channel *
• Second Audio Program (SAP) For details, see page 13.
* RMS rating, into 8 ohms, 50 to 20,000 Hz ±3db, with less than
1% THD.
Creative Entertainment
• Advanced Color Picture-in-Picture lets you watch two programs
at once (with VCR).
• Channel Labeling lets you label channel numbers with up to
4-letter names (eg. NBC, VH–1, ESPN). For details, see page 19.
One Minute Manual
• On-Screen Menus for simple operation of picture, sound, and
set-up functions by remote control. For details, see pages 11-14.
.• AutoProgramming automatically searches for and stores all
active channels. Eliminates the need for manual set-up. For
details, see page 21.
• Frequency Synthesis Tuning automatically and accurately tunes
each channel.
• Automatic VCR Setup with the push of a button, your TV is ready
for VCR play: both TV and VCR turn on and TV tunes to correct
channel/input. For details, see page 23.
• Automatic Cable Box Setup offers convenience when cable
company requires you to use cable box. For details, see page 25.
• On-Screen Clock/Channel Display For details, see page 3.
• Picture Reset For details, see page 7.
Connections
Gold Plated Phono for Superior Performance:
• Two Sets of Audio/Video Inputs for VCR, Laserdisc player,
Camcorder etc. For details, see pages 43-45.
• One Set of Audio/Video Outputs for video dubbing. For details,
see pages 44-46.
• One Set of Volume-Controlled Audio Outputs (
remote volume when connected to an external amplifier. For
details, see page 46.
Other Connections to Expand Your System:
• S-Video input connector for direct input from your S-VHS VCR,
Camcorder, etc. For details, see pages 44 and 45.
• Four Speaker Jacks to allow hook up of optional external
speakers. For details, see pages 48-49.
• Dual RF Inputs to allow direct connection of up to two basic
cable, cable box, or other RF sources. For details, see pages
38-40.
• Front-Mounted Stereo Headphone Jack for private listening with
optional headphones. For details, see page 10.
At Your Command
• The P
RO
need to teach additional or new codes. Operation is as easy as
entering a channel. It operates all major ProScan TV and VCR
functions. Operates the basic functions of 81 different VCR
brands and 39 different brands of cable boxes, eliminating the need
for additional remotes.
• The P
RO
functions for the ultimate in simplicity.
At Your Service
Our Human Touch policy offers all these valuable
benefits:
• 1-800-PROSCAN Call our toll-free number for information about
your ProScan product.
• Nationwide Independent Authorized Service Centers
• P S
RO CAN
parts and labor for one year, picture tube for two years. For
details, see page 52.
) to retain
HI-FI
S Universal Remote is preprogrammed so there's no
CAN
S Simple Remote–6 buttons control everyday TV
CAN
Limited Warranty for U.S.A. Home service of all
