PCI Express Boards
6. You will see the following screen. Press Enter to select the MOXA Multiport Serial Board you installed by port
and by model. For example, if you installed the CP-104EL, select 4 ports and then CP-104EL.
Board No.
1
2
3
4
7. The board's basic information, such as I/O address, Bus No., and Device No., will be shown. The SCO
system will assign the resources automatically to the PCI Express board you selected.
8. Next, press "Esc" to exit and reboot your computer.
NOTE
Steps 9 and 10 are only for the CP-132EL Series and CP-114EL Series
9. After rebooting, type "moxaadm". When you see MAIN MENU, select Interface Configuration to set your
Resister and Interface. For example, if you want to set one of the CP-114EL ports as RS-422 and 120Ω, you
have to select RS-422 and 120Ω.
10. Save your Interface Configuration and then reboot the computer again.
11. Note that whenever you change a MAIN MENU item, you need to reboot your computer.
MOXA Smartio/Industio Family Installation Utility (Ver 1.11)
Smartio/Industio Family Basic Configuration
Board Type I/O Address
None ------------
None ------------
None ------------
None ------------
PgDn: getty Setting
Enter: Confirm Input Value
Interrupt
------------
------------
------------
------------
Esc: Exit
Tab: Change Item
3-54
Software Installation
Bus/Dev No.
------------
------------
------------
------------
