- Page 1 PCI Express Multiport Serial Board Series Quick Installation Guide Version 2.4, January 2023 Technical Support Contact Information www.moxa.com/support 2022 Moxa Inc. All rights reserved. P/N: 1802001182045 *1802001182045*...
- Page 2 Overview Moxa’s new PCI Express Multiport Serial Boards series is designed for POS and ATM applications and for use by industrial automation system manufacturers and system integrators. Package Checklist Before installing the PCI Express board, verify that the package contains the following items: •...
- Page 3 Use the Moxa terminal utility to test the tty ports: #cd /moxa/mxser/utility/term #./msterm 3. Intelligent RS-485 The following models support the intelligent RS-485 feature: • CP-134EL-A-I without a cable • CP-134EL-A-I-DB9M • CP-134EL-A-I-DB25M • CP-138E-A-I without a cable •...
- Page 4 3.4. Manually configure the Pull Up/Down resistor and the terminator resistor with the assigned values: #./muestty –p (assigned value) /dev/ttyMUE1 #./muestty –t (assigned value) /dev/ttyMUE1 3.5. Do the diagnosis again: #./muestty -d /dev/ttyMUE1 Pin Assignments CP-102E / CP-102EL Male DB9 (CBL-M25M9x2-50 for CP-102EL) DB9 male RS-232...
- Page 5 RS-422/ RS-232 RS-485-2W RS-485-4W RxD+(B) Data+(B) TxD+(B) – – – – – – – TxD-(A) – RxD-(A) Data-(A) CP-134EL-A-I Male DB9 (CBL-M44M9x4-50) DB9 male RS-422/ RS-232 RS-485-2W RS-485-4W TxD-(A) – TxD+(B) – RxD+(B) Data+(B) RxD-(A) Data-(A) – – – –...
- Page 6 Male DB25 (CBL-M44M25x4-50) DB25 male RS-422/ RS-232 RS-485-2W RS-485-4W RxD+(B) Data+(B) TxD+(B) – – – – – – – TxD-(A) – RxD-(A) Data-(A) CP-116E-A Male DB9 (OPT8-M9+ / CBL-M68M9x8-100) DB9 male RS-422/ RS-232 RS-485-2W RS-485-4W TxD-(A) – TxD+(B) – RxD+(B) Data+(B) RxD-(A) Data-(A)
- Page 7 사용자안내문 이 기기는 업무용 환경에서 사용할 목적으로 적합성 평가를 받은 기기로서 가정용 환경에서 사용하는 경우 전파간섭의 우려가 있습니다. 사용자안내문 (User Guide) 이 기기는 업무용 환경에서 사용할 목적으로 적합성평가를 받은 기기로서가정용 환경에서 사용하는 경우 전파간섭의 우려가 있습니다. (This equipment has KC approval for use in industrial environments and could possibly interfere with household equipment.) 기...
