CP-134EL-A-I Specifications

Hardware
Connectors
Comm. Controller
Interface
Bus Interface
Number of Ports
Max No. of Boards
Signal
RS-422
4-wire RS-485
2-wire RS-422
Performance
Baudrate
Configuration
Data Bits
Stop Bits
I/O Address/IRQ
Parity
Flow Control
Power and Environment
Power Requirement
Operating Temperature
Operating Humidity
Storage Temperature
ESD Protection
Surge Protection
Regulatory Approvals
Warranty
Female DB 44
16C550C Compatible
PCI-Express x 1
4
4
TxD+(B), TxD-(A), RxD+(B), RxD-(A), GND
TxD+(B), TxD-(A), RxD+(B), RxD-(A), GND
Data+(B), Data-(A), GND
50 bps to 921.6 kbps
5, 6, 7, 8
1, 1.5, 2
BIOS assigned
None, Even, Odd, Space, Mark
RTS/CTS, XON/XOFF
3414 mA (3.3V)
0 to 55°C (32 to 132°F)
5 to 95% RH
-20 to 85°C (-4 to 185°F)
Embedded 15 kV ESD Protection
4 kV
EN55022, EN55024, EN61000-3-2, EN61000-3-3, IEC 61000-4-2, IEC
61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC
61000-4-8,
IEC 61000-4-11 FCC Part 15 Class B
5 years
