PCI Express Boards

Moxa Serial Comm Tool

For application development, Moxa provides an easy-to-use serial communication library called PComm that
runs under Windows NT/95/98/2000/XP/2003. Use this library to develop your own applications with Visual
Basic, Visual C++, Borland Delphi, etc. Utilities such as Data Scope, Monitor, Terminal Emulator, and
Diagnostics are included to make it easier to debug, monitor communication status, provide terminal emulation,
and transfer files.
Intelligent RS-485
With Intelligent RS-485, you only need one click to automatically tune the Pull High/Low and Termination
resistors and get your system ready to go!

Applications

The PCI Express boards are suitable for many different applications, including:
• Internet/Intranet Connections
• Remote Access
• Multi-user Applications
• Industrial Automation
• Office Automation
• Telecommunications
• PC-based Vending Machines and Kiosks
• POS (Point-of-Sale) Systems

Features

The PCI Express boards have the following outstanding features:
• PCI Express ×1 compliant
• Low profile board for compact-sized PCs
• Data flow LED display onboard
• 128-byte FIFO and on-chip H/W, S/W flow control
• 50 bps to 921.6 kbps transmission speed
• Embedded 15 kV ESD surge protection
• Drivers are provided for all major industrial platforms: Windows 2000, Windows XP/2003/Vista/2008
(32-bit/64-bit), Windows 7 (32-bit/64-bit), Windows 8 (32-bit/64-bit), Windows 2012 (64-bit), Windows
CE, Windows XP Embedded, DOS, Linux (32-bit/64-bit), SCO

Package Checklist

The following items are included in the PCI Express board package:
• PCI Express serial board
• Low profile bracket
• Documentation and Software CD-ROM
• Quick Installation Guide
NOTE Please notify your sales representative if any of the above items are missing or damaged.
1-3
Introduction
