Ski-Doo REV series 2007 Operator's Manual page 150

Strap Adjustment
All Models except Summit
A03F0QB
TYPICAL
1. Increase or decrease strap length by bolting to a different hole
Coupling Blocks — Handling
SC-4 Suspension Only
• Ride at moderate speed and check for desired handling.
• If handling requires adjustment, turn both left and right blocks by
90 to the desired position.
NOTE: There are four possible adjustment positions. Side of block
with the desired adjustment number must be facing the rubber stop-
per.
Both blocks must be set at the same position. Otherwise ve-
hicle behavior may be unpredictable and suspension may be-
come warped.
Use tool provided in tool bag to adjust coupling blocks.
_________________________
148
WARNING
1
