Ski-Doo REV series 2007 Operator's Manual page 121

– NEVER place any cargo on either of the 2 passenger seats,
as cargo could collide with occupants.
– If you ride with the 2 passenger seats installed, your cargo
must be placed only in the suitcases.
– If you want to ride with 1 passenger and some cargo, do
not put the cargo on the passenger's seat left unused. You
must instead remove the "2+1" seat and slide the passen-
ger's seat from the rearmost position, to the position just
behind the operator's seat. This will create space behind
the passenger's seat to place your cargo.
2 Passenger's Seat Set-Up
The GTX Limited can be converted into a snowmobile with 2 seats
instead of 3, by removing the middle "2+1" seat and installing the
passenger's seat with the backrest immediately behind the opera-
tor's seat.
A33A2XA
2 PASSENGER'S SEAT SET-UP
1. Driver seat
2. Passenger's seat
_________________________
WARNING
2 1
119
