600B610/01
July 2000

INSTALLER GUIDE

Dream Fireslide
INSET LIVE FUEL EFFECT GAS FIRE
WITH EITHER
Brass Front
(MODEL 9500433)
Chrome Front
(MODEL 9500434)
Black Front
(MODEL 9500435)
THIS APPLIANCE IS FOR USE WITH NATURAL GAS (G20)
WHEN CONVERTED USING VALOR CONVERSION KIT No.591159 THIS
APPLIANCE IS FOR USE WITH PROPANE GAS (G31)
THIS APPLIANCE IS FOR USE IN THE UNITED KINGDOM (GB) AND
THE REPUBLIC OF IRELAND (IE) ONLY
We trust that these instructions give sufficient details to enable this appliance to be installed and maintained satisfactorily. However if
further information is required, our Valor advice line will be pleased to help.
Ring 0345 626 341 (local call rates apply).
INSTALLER: Please leave these instructions with the owner

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dream Fireslid 9500433 and is the answer not in the manual?

Questions and answers

Summary of Contents for Valor Dream Fireslid 9500433

  • Page 1: Installer Guide

    We trust that these instructions give sufficient details to enable this appliance to be installed and maintained satisfactorily. However if further information is required, our Valor advice line will be pleased to help. Ring 0345 626 341 (local call rates apply).
  • Page 2 BS EN ISO 9001 quality system accepted by the British Standards Institute. The Highest Standards Valor is a member of the Society of British Gas Industries which works to ensure high standards of safety, quality and performance.
  • Page 3: Table Of Contents

    Valor 600B610_01 7/12/00 3:22 PM Page 3 LIST OF CONTENTS Page INSTALLER SECTION.........................4 APPLIANCE DATA ..........................4 GENERAL INSTALLATION REQUIREMENTS...................4 PRELIMINARY CHECKS........................6 Unpacking............................6 Check Ignition Spark........................6 Check The Fireplace........................7 Fireplace Flue Pull..........................7 PREPARING APPLIANCE FOR INSTALLATION..................7 Gas Supply Connection........................7 Appliance Preparation........................8 INSTALLATION TO FIREPLACE.....................8...
  • Page 4: Installer Section

    Valor 600B610_01 7/12/00 3:22 PM Page 4 INSTALLER GUIDE 1.APPLIANCE DATA 2. GENERAL INSTALLATION REQUIREMENTS This product uses fuel effect pieces containing Refractory Ceramic Fibres (RCF), which The installation must be in accordance with are man-made vitreous silicate fibres. Excessive these instructions.For the user’s protection,...
  • Page 5 Valor 600B610_01 7/12/00 3:22 PM Page 5 INSTALLER GUIDE If the appliance is intended to be installed to a chimney which was previously used for solid fuel, the flue must be swept clean prior to installation. All flues should be inspected for soundness and freedom from blockages.
  • Page 6: Preliminary Checks

    Valor 600B610_01 7/12/00 3:22 PM Page 6 INSTALLER GUIDE A twin wall metal flue system area from which ventilation for the 2.10.2 conforming to BS715, the flue appliance is taken, if it does not affect Diameter being a minimum of 125mm the safe performance of the appliance.
  • Page 7: Check The Fireplace

    Valor 600B610_01 7/12/00 3:22 PM Page 7 INSTALLER GUIDE Depress the slider as far as it will go. fireplace should be reasonably flat over 3.2.2 This should close the ignition circuit. the area covered by the convection box Sparks should be seen tracking from the...
  • Page 8: Appliance Preparation

    Valor 600B610_01 7/12/00 3:22 PM Page 8 INSTALLER GUIDE Appliance Preperation 4.2. 5.INSTALLATION TO FIREPLACE Disconnect the control linkage from the 4.2.1 burner unit by removing the shouldered screw which joins the control linking bar Cables and eyebolts are supplied for the to the control pivot unit (see figure 7).
  • Page 9: Burner & Fascia Installation

    Valor 600B610_01 7/12/00 3:22 PM Page 9 INSTALLER GUIDE the “V” shaped brackets near the bottom Store the free length of the cables in 5.12 front sides of the convection box (see convection box. This will allow easy figure 10).
  • Page 10: Preliminary Burner Checks

    Valor 600B610_01 7/12/00 3:22 PM Page 10 INSTALLER GUIDE Connect the supply line to the appliance. gradually slide the control knob upwards. If connection is from the left side make The burner flames should gradually sure that the pipe is formed to allow the...
  • Page 11: Burner Trim Fitting

    Valor 600B610_01 7/12/00 3:22 PM Page 11 INSTALLER GUIDE Burner Trim Fitting Position the burner trim over the front flanges of the burner tray and firmly push it down as far as it will go. See figure 13. figure 15...
  • Page 12: Full Operating Checks

    Valor 600B610_01 7/12/00 3:22 PM Page 12 INSTALLER GUIDE Place two coals each side of the centre loose coal. Make sure that they bridge the space between the front and rear base coals. See figure 18. figure 21 8.FULL OPERATING CHECKS...
  • Page 13: Check For Spillage

    Valor 600B610_01 7/12/00 3:22 PM Page 13 INSTALLER GUIDE Open the isolating valve on the inlet elbow. Check For Spillage 8.1.2 Slide the button to the bottom (ignition) A spillage check must be made before 8.1.3 position marked ?. Retain in this position leaving the installed appliance with the to ignite the pilot.
  • Page 14: Final Review

    Valor 600B610_01 7/12/00 3:22 PM Page 14 INSTALLER GUIDE This is explained in the Owner’s manual 9.FINAL REVIEW under the section ‘Operating the Fire’. Place the fire front castings in position. Point this out to the customer before Visually inspect the appliance. Clean off leaving.
  • Page 15: To Remove The Ignition Microswitch

    Valor 600B610_01 7/12/00 3:23 PM Page 15 INSTALLER GUIDE clearly labelled as RCF waste. This is not classified as “hazardous waste” and may be disposed of at a tipping site licensed for the disposal of industrial waste. Protective clothing is not...
  • Page 16: To Replace The Control Slide Knob

    Valor 600B610_01 7/12/00 3:23 PM Page 16 INSTALLER GUIDE microswitch leads and pull the leads clear of the thermocouple interrupter block (see figure 26). Detach the bridging bracket, microswitch 10.2.4 assembly and insulation pad by removing two screws (see figure 25).
  • Page 17: To Remove The Thermocouple Interrupter Block

    Valor 600B610_01 7/12/00 3:23 PM Page 17 INSTALLER GUIDE projects up from the fire case base. See cage to the pilot unit & burner. figure 29. Carefully remove the dust cage and place To remove the thermocouple interrupter aside. See figure 31.
  • Page 18: To Remove The Shut-Off Tap

    Valor 600B610_01 7/12/00 3:23 PM Page 18 INSTALLER GUIDE sure that it locates squarely onto the pilot unit without any gaps between the cage edges and the pilot unit. 3. When the thermocouple is removed from the interrupter block, the microswitch lead terminals in the interrupter block will be loose.
  • Page 19: To Remove The Main Burner Injector

    Valor 600B610_01 7/12/00 3:23 PM Page 19 INSTALLER GUIDE position. Make sure that the centre section of the combination plaque is between the two plaques. If there is any play between the plaques and the end retaining flanges, push the plaques...
  • Page 20: Short List Of Spares

    Valor 600B610_01 7/12/00 3:23 PM Page 20 INSTALLER GUIDE 11. SHORT LIST OF SPARES KEY NO. DESCRIPTION NO. OFF MAKER’S PART NO. Shut-off tap 540899 Gas flow rate controller 540919 Thermocouple interrupter block 522389 Ignition microswitch 540959 Gas shut-off microswitch...
  • Page 21: Users Instructions

    If you wish to replace any of the owner replaceable parts listed below, please To order spares or for sales information: contact Valor Sales on 0121 386 6260 for your nearest stockist of these parts. When VALOR SALES 0121 386 6260.
  • Page 22 USERS INSTRUCTIONS Place two coals each side of the centre 3. FITTING THE CERAMIC COALS loose coal. Make sure that they bridge the space between the front and rear base Place the front base coal in the burner coals. See figure 6. compartment so that it rests on the edges at the sides and front.
  • Page 23 USERS INSTRUCTIONS iii) The appliance will operate to its maximum 2. CLEANING potential if the flue is primed during the first 20 ñ 30 minutes of operation.To Turn the fire off and allow it to cool before do this, simply slide the control button attempting any cleaning.
  • Page 24: Operating The Fire

    USERS INSTRUCTIONS Slide the control button to the bottom 1. OPERATING THE FIRE (ignition) position marked ? In this position, the electronic ignition system The Oxysafe flame sensing & flue should cause a series of sparks which blockage safety system. should light the pilot.
  • Page 25 USERS INSTRUCTIONS SAFETY IF YOU SMELL GAS DON’T SMOKE EXTINGUISH ALL NAKED FLAMES DON’T TURN ELECTRICAL SWITCHES ON OR OFF TURN OFF THE GAS SUPPLY AT THE METER OPEN DOORS AND WINDOWS TO GET RID OF THE GAS IMMEDIATELY CALL THE GAS EMERGENCY SERVICE - SEE YOUR LOCAL TELEPHONE DIRECTORY As with any gas appliance, this fire must be installed 6.
  • Page 26 If you require further assistance or any advice about gas in general, the Valor AdviceLine will be pleased to help. Please telephone 0345-626341 (local call rates apply in the United Kingdom).
  • Page 27 BS EN ISO 9001 quality system accepted by the British Standards Institute. The Highest Standards Valor is a member of the Society of British Gas Industries which works to ensure high standards of safety, quality and performance.
  • Page 28 THE REPUBLIC OF IRELAND (IE) ONLY This Owner Manual is intended to help you care for your Valor gas fire. Please read carefully before using your gas fire and keep for future reference. This Owner manual gives sufficient details to enable your gas fire to be operated and maintained.
