Decorative Vented Gas Fireplace
Installation & Operating Instructions
Please read this manual BeFORe installing and operating this appliance.
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury or loss of life.
Do not store or use gasoline or other
fl ammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMeLL GAS
• Do not try to light the appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call
the fi re department.
Installation and service must be performed
by a qualifi ed installer, service agency or the
gas supplier.
4000192-12
©2011, Miles Industries Ltd. All rights reserved.
P
ORTRAIT
DECORATIVE
Models 922eCN/eCP
With Coal effect fuel
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Manufactured by
MILeS INDUSTRIeS LTD.
British Columbia, Canada
www.valorfi replaces.com
This appliance may be installed in an
after-market permanently located,
manufactured (mobile) home where not
prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certifi ed kit is used.
This appliance is a domestic room-heating
appliance. It must not be used for any other
purposes such as drying clothes, etc.
This appliance is suitable for installation in a
bedroom or bed sitting room.
Massachusetts: The piping and fi nal
gas connection must be performed by a
licensed plumber or gas fi tter in the State of
Massachusetts.
Ce guide d'installation est également offert en français.
Advertisement
Table of Contents
Related Manuals for Valor PORTRAIT 922ECN
Summary of Contents for Valor PORTRAIT 922ECN
- Page 1 ORTRAIT DECORATIVE Models 922eCN/eCP Decorative Vented Gas Fireplace With Coal effect fuel Installation & Operating Instructions INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. Please read this manual BeFORe installing and operating this appliance.
- Page 2 Thank You ... For purchasing a Valor by Miles Industries. Your new radiant gas heater is a technical appliance that must be installed by a qualified dealer. Each Valor fireplace is fully tested during the production process for your safety and comfort.
-
Page 3: Table Of Contents
Table of Contents ◊ Safety and Warning Information ..............4 ◊ Specifications ....................5 ◊ Options .......................6 Choice of Fronts ..................6 Location & Clearances ................7 Appliance Preparation ................8 Gas Supply Installation ................10 Firebox Installation (insert application only) ........11 Remote Control Installation ..............12 Ceramic Fuel Bed Installation ..............13 923ACF Adorn Cast Front Installation ...........15 Adorn Safety Guard Fitting ..............15... -
Page 4: Safety And Warning Information
Safety and Warning Information ReAD and UNDeRSTAND all instructions carefully This unit MUST be used with a vent system as before starting the installation. FAILURe TO FOLLOW described in this installation manual. NO OTHeR vent these installation instructions may result in possible fire system or components MAY Be USeD. -
Page 5: Specifications
The unit does not require an electrical power source. Ratings Supply Gas Model 922ECN is for use only with natural gas. Model Altitude (Ft) 0-4500 * 922ECP is for use only with propane gas. The supply Input Max. (Btu/h) -
Page 6: Options
Options Fronts (required) 976BRK Bedroom Kit—Includes optional thermostat handset and wiring harness (for use in Canada only). 923ACF—Adorn Cast Front. 3336 Closure Plate—For insert installations to cover 539 or 549 Cast Iron Arch Fronts—Also require up to 33” high x 36” wide. #540WDK Wire Dress Guard, supplied separately. -
Page 7: Location & Clearances
Location & Clearances This appliance must not be connected to a chimney before installation of the appliance. The liner must be a flue serving a separate solid-fuel burning appliance. type approved by the enforcing authority and installed Note: The State of Massachusetts requires that any in accordance with the manufacturer’s instructions. -
Page 8: Appliance Preparation
Location & Clearances enclosures Constructed Using Combustible Materials (ZC Installations) • Optional 975ZCK Zero Clearance Kit must be used when installing the 922 fireplace into any application other than as an insert into an approved solid-fuel burning fireplace cavity and chimney. Complete installation instructions are packed with the 975ZCK. - Page 9 Appliance Preparation Install Base Coal Support Install base coal support (packed loose) to back of firebox using 3 screws as shown below. Remove Burner Module (optional) In some cases, to make gas piping easier, it may be convenient to remove the burner module from the firebox—note the location of the gas inlet before removing the burner module.
-
Page 10: Gas Supply Installation
Gas Supply Installation • The appliance is supplied for supply gas connection • The appliance must be isolated from the gas supply at the left hand side of the case. There is also a piping system by closing its individual manual shut- gas line access at the rear of the firebox for insert off valve during any pressure testing of the gas applications. -
Page 11: Firebox Installation (Insert Application Only)
Firebox Installation (insert application only) Refer to 975ZCK installation manual for ZC firebox 4. Insert a wall plug into each hole. installation. 5. Secure the collar on the vent connector unit to the To aid chimney liner connection, it may be necessary 4”... -
Page 12: Remote Control Installation
Remote Control Installation Caution! Do not fit the batteries into the remote control receiver until the wires are connected to the burner control unit, as a short circuit could result in the destruction of the electrical components. • Connect the wiring harness to the receiver box, by pushing the wire connector on to the receiver circuit board. -
Page 13: Ceramic Fuel Bed Installation
Ceramic Fuel Bed Installation Ceramic Walls Installation 1. Locate the ceramic rear wall on top of the base coal support as shown. 2. Insert the right hand sidewall at an approximate 30-degree angle between the firebox side and the burner. Swing the top of the sidewall to the vertical position and locate behind the upper baffle—see figure below. -
Page 14: Ceramic Coals Installation
Ceramic Fuel Bed Installation Ceramic Coals Installation 1. Rest the base coal on the supports just behind the burner and let it rest against the base coal support at the back of the firebox. 2. Place the left front coal in position behind the metal lip at the front of the firebox. -
Page 15: 923Acf Adorn Cast Front Installation
923ACF Adorn Cast Front Installation 1. Carefully lift the casting. Place it against the 3. Slide the front casting/surround sideways, if fireplace front surface so that the retaining strip necessary, to align the bottom fixing holes with at the back of the casting is above the two upper those in the convection box. -
Page 16: Operation Checks
Operation Checks Final Checks Check ignition, pilot stability, burner flames, and the full range of movement of the flame adjustment knob. See owner’s lighting instructions further on in this manual for full details. Aeration adjustment As described in manual, burner aeration is adjustable. For the vast majority of installations, no adjustment will be necessary. -
Page 17: Owner's Information
PILOT position. See full lighting instructions on next page. The Valor Remote Control System Your Valor Remote Control helps you get the comfort, Correct Flame Appearance convenience and aesthetics you want from your Valor The appliance area must always be kept clear and Gas Fireplace. -
Page 18: Lighting Instructions
Lighting Instructions FOR YOUR SAFeTY ReAD BeFORe LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot, which must be lighted by hand. When lighting the pilot, follow these instructions exactly. -
Page 19: Warranty
Warranty If you have a problem with this unit, please contact your dealer or supplier immediately. Under no circumstances should you attempt to service the unit in any way by yourself. The warranties in paragraphs 1 and 2 are provided only to the first purchaser/user of this unit, are not transferable and are subject to the conditions and limitations in paragraphs 3, 4 and 5. -
Page 20: Replacement Parts
Replacement Parts Code Description Part. no. Code Description Part. no. Drafthood retainer (2) 4000166 Flexible pipe assy 4000345 Spigot slide plate assy 4000199 Bypass screw LPG (incl. w 4003100S) Downdraft 4000359 Control valve GV34 4003100S Top plate 4000332AH Interruptor block 4000202 Mounting brkt Adorn x2 4000348... - Page 21 Replacement Parts 9a/b 922 BODY 15a/b 17a/b 25A/B 33A/B 44 45...
- Page 22 Replacement Parts...
- Page 23 Thank You ... For purchasing a Valor by Miles Industries. Your new radiant gas heater is a technical appliance that must be installed by a qualified dealer. Please circle where appropriate - ask your installer or your dealer if in doubt. The information provided will be used for customer records only.
- Page 24 Fold here Postage needed Miles Industries Ltd. 190 - 2255 Dollarton Highway North Vancouver, BC V7H 3B1 Canada Online Warranty registration at www.valorfireplaces.com Were you given all documentation and manuals for your product? Thank you for choosing a Valor Product...
