WARNING: If the information in these
instructions is not followed exactly, a
fire or explosion may result causing
property damage, personal injury or
loss of life.
- Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
-
•
Do not try to light any appliance.
•
Do not touch any electrical switch: do not
use any phone in your building.
•
Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
•
If you cannot reach your gas supplier, call
the fire department.
- Installation and service must be performed
by a qualified installer, service agency or
the gas supplier.
Vous pouvez vous procurer un exemplaire en langue Française de cette brochure chez votre marchand.
by
Model 922ECN ( Nat Gas )
Model 922ECP ( LP Gas )
Open Front
Decorative Vented Gas Fireplace
(With Coals)
Installation and Owner's Manual
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Manufactured by
MILES INDUSTRIES LTD.
British Columbia, Canada
PLEASE READ THIS MANUAL BEFORE
INSTALLING AND OPERATING THIS
HEATER.
This appliance may be installed in an
aftermarket permanently located,
manufactured (mobile) home, where not
prohibited by local codes.
This appliance is only for use with the type of
gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
This appliance is a domestic room-heating
appliance. It must not be used for any other
purpose such as drying clothes etc.
This appliance is suitable for installation in a
bedroom or bed sitting room.
Warning: This product must be installed by
a licensed plumber or gas fitter when
installed within the Commonwealth of
Massachusetts.
4000192/04
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Valor 922ECN
Summary of Contents for Valor 922ECN
- Page 1 Model 922ECN ( Nat Gas ) Model 922ECP ( LP Gas ) Open Front Decorative Vented Gas Fireplace (With Coals) Installation and Owner’s Manual INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. PLEASE READ THIS MANUAL BEFORE...
-
Page 2: Table Of Contents
CONTENTS SAFETY INFORMATION.................................3 OPTIONS ....................................4 GENERAL DATA..................................4 LOCATION IN THE ROOM ( insert application )………………………………………………………………………………… 5 ( Z.C Application )………………………………………………………………..…………6 SUPPLY GAS ..................................7 PACK CONTENTS ..................................7 APPLIANCE PREPARATION ..............................8 GAS SUPPLY INSTALLATION...............................9 FIREBOX INSTALLATION..............................10 10. REMOTE CONTROL INSTALLATION ..........................11 11.1 CERAMIC WALLS INSTALLATION .............................12 11.2.CERAMIC COALS INSTALLATION .............................13 12. -
Page 3: Safety Information
1. SAFETY INFORMATION Due to high temperatures, the appliance should If any changes are made to the room construction be located out of traffic and away from furniture in the vicinity of the appliance after installation and draperies. (e.g. additional mantle etc.) make sure that the changes conform to the installation requirements Children and adults should be alerted to the in this manual. -
Page 4: Options
This appliance must be installed in accordance with local codes, if any, or in the absence of local codes follow the National Fuel Gas Code ANSI Z223.1 or Canadian Installation Code CAN-1-B149. Only qualified licensed or trained personnel should install the appliance. 3.1 Venting This appliance must be connected to an approved venting system. 922ECN 922ECP 3.2 Ratings Altitude (Ft) 0-4500 Input Max. -
Page 5: Location In The Room ( Insert Application )
4. LOCATION IN THE ROOM This appliance must not be connected to a chimney flue serving a separate solid-fuel burning appliance. Note: The State of Massachusetts requires that any flue damper must be removed or permanently welded in the open position. The appliance can be installed in the following constructions: Solid fuel (Non-combustible) fireplaces As supplied, this appliance can be installed as an inset in an existing solid fuel type fireplace with a chimney and 4"... -
Page 6: ( Z.c Application )
4.2 Enclosures Constructed Using Combustible Materials ( Z.C Installations) Optional # 975 ZCK zero clearance kit must be used when installing the 922 Fireplace into any application other than as an insert into an approved solid fuel burning fireplace cavity and chimney. Complete installation instructions are packed with the 975 ZCK. -
Page 7: Supply Gas
5. SUPPLY GAS Model 922ECN is for use only with natural gas. Model 922ECP is for use only with propane gas. The supply pressure must be between the limits shown in section 3 of this manual. The supply connection is ”NPT male thread. -
Page 8: Appliance Preparation
7. APPLIANCE PREPARATION 7.1. Check ignition spark The pilot burner and electrode unit is at the left end of the burner. Push in the lighting knob and turn counter-clockwise through the “IGN” position to “PILOT”. A spark should flash across from the pilot electrode to the pilot burner shield. -
Page 9: Gas Supply Installation
8. GAS SUPPLY INSTALLATION The appliance is supplied for supply gas connection at the left hand side of the case. There is also a gas line access at he rear of the firebox for insert applications, see fig 7.The zero clearance kit does not have access at the rear. -
Page 10: Firebox Installation
9. FIREBOX INSTALLATION ( insert Application only ) 9.1 Refer to 975 ZCK installation Manual for Z.C Firebox installation. 9.2 To aid chimney liner connection it may be necessary to first remove the vent collar connector from the top of the firebox ( see fig 9a ) 9.3 Remove the burner module from the firebox, see fig 9 . -
Page 11: Remote Control Installation
10. REMOTE CONTROL INSTALLATION Caution! Don’t connect the batteries to the remote control receiver until the wires are connected to the burner control unit, as short circuit could result in destruction of the electrical components. When installing the remote please refer to figures 10 and 11. •... -
Page 12: Ceramic Fuel Bed Installation
11. CERAMIC FUEL BED INSTALLATION 11.1. Ceramic Walls Installation Locate the ceramic rear wall on top of the base coal support as shown in fig 12. Insert the right hand sidewall at approx 30 degree angle between the firebox side and the burner. Swing the top of the sidewall to the vertical position and locate behind the upper baffle (see fig13). -
Page 13: Ceramic Coals Installation
11.2. Ceramic Coals Installation Rest the base coal on the supports just behind the burner and let it rest against the base coal support at the back of the firebox. See fig 14. Place the left front coal in position behind the metal lip at the front of the firebox. The side projection on this coal should be near the middle front of the firebox. -
Page 14: Adorn Cast Front Installation
#923 ADORN CAST FRONT INSTALLATION 12.1 Carefully lift the casting. Place it against the fireplace front surface so that the retaining strip at the back of the casting is above the two upper retaining brackets at the top of the convection box. Lower the casting making sure that the rear retaining strip locates fully over the retaining brackets on the convection box (See figure 19). -
Page 15: Windsor Cast Arch Front Installation
#539/549 WINDSOR ARCH CAST FRONT INSTALLATION 14.1 All Windsor Arch fronts mounted to 922 fireboxes require a 540 WDK wireguard and mounting hardware, see fig 23. Note – Bottom of Firebox must be installed flush with the finished hearth height or casting will not install properly. Castings must rest on secure hearth or floor as the firebox and brackets will not support castings on their 14.2 Install mounting brackets and burner tray cover to the firebox... -
Page 16: Operation Checks
15. OPERATION CHECKS 1. Check ignition, pilot stability, burner flames, and the full range of movement of the flame adjustment knob. See owner’s lighting instructions further on in this manual for full details, see fig 28. 2. Aeration adjustment As described in section 17, burner aeration is adjustable. For the vast majority of installations, no adjustment will be necessary. -
Page 17: Owners Information
See full lighting instructions on next page. The Valor Remote Control System Your Valor Remote Control helps you get the comfort, convenience and aesthetics you want from your Valor Gas Fireplace. Setting the Flame Press either of the large “up” or “down” buttons. -
Page 18: General Servicing
16.3. Checks A periodic check of the pilot and burner flames should be made. Check after the fire has been on for at least 30 minutes. The pilot flame must cover the tip of the thermocouple probe. The main burner flame pattern will vary from appliance to appliance depending on the type of installation and climatic conditions. -
Page 19: Lighting Instructions
YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot, which must be lighted by hand. When lighting the pilot, follow these instructions exactly.
