Controller Menus

Set Antenna GPS and Find Antenna Angle
The antenna makes use of the GPS's information to search for the satellite
quickly. The more precise the GPS's information is, the quicker the antenna
is able to search for the satellite. The method to input information into
the GPS is to push the "Set GPS" button after keying in the latitude and
longitude information on "City GPS". Pushing the "Add City" button stores
the GPS's information. By selecting the stored region in the list box, the
GPS information of that region is displayed. The Intellian i2 satellite TV
antenna system utilizes the GPS data to locate the satellite faster.
Figure 27 : Antenna Angle and GPS Information
52
Command Buttons
• Load GPS Files – Reads various city information from the GPS files.
• Add City – Adds the name of city and its GPS information to GPS files.
• Delete City – Deletes the name of city and its GPS information from the
GPS files.
• Set GPS – Inputs the indicated GPS information on display to antenna.
• Find Angles & Skew Antenna GPS – Finds the current antenna angle and
skew angle in relation to the longitude (orbit position) of satellite and
antenna current GPS.
• Find Angles & Skew City GPS – Finds the current antenna angle and
skew angle in relation to the longitude (orbit position) of satellite and city GPS.
