Intellian i2 Installation And Operation Manual page 44

Intellian Satellite TV Antenna Systems
Executing Antenna Diagnosis
It is possible to see the antenna's status by reviewing the results of diagnosis of the antenna. Refer
to the following codes to understand the diagnosis results.
SETUP MODE ?
YES NO
SET SAT PAIR ?
PREV YES NEXT
X11
ANT DIAGNOSIS ?
PREV YES NEXT
CODE 101 TESTING
RESULT: ? EXIT
44
1. Press YES to enter setup mode.
2. Press NEXT eleven times to enter antenna
diagnosis mode.
3. Press YES to diagnose the antenna.
4. CODE 101 is being tested.
Press EXIT to return to main setup mode.
CODE 101 PASSED.
RESULT: ●
EXIT
5. CODE* 101 has passed.
Press EXIT to return to main setup mode.
