- Page 1 INTRODUCTION INSTALLING THE ANTENNA System Package Antenna Unit ACU (Antenna Control Unit) Installation Kit Planning the Installation Selection of Antenna Installation Site System Cables Power Requirement Tools Required for Installation Antenna Installation Unpacking the Wooden Crate Remove Antenna Shipping Restraints Antenna Dimensions Antenna Mounting Templates Preparing Antenna Supporting Pole...
-
Page 2: System Package
– Marine Satellite Television System System Package The Intellian t110W/t130W consists of two major units, an antenna assembly unit and the antenna control unit. Antenna Unit The antenna unit includes an antenna pedestal inside a radome assem- bly unit. The pedestal consists of the satellite antenna main dish and... - Page 3 INSTALLING THE ANTENNA Antenna Control Unit (ACU) The Antenna Control Unit (ACU) provides power to the antenna and controls various settings of the antenna. Additionally, VFD (Vacuum Fluorescent Display) allows for you to operate the ACU in the dark. Front panel Rear panel...
- Page 4 – Marine Satellite Television System The functions of the ACU are as follows : • System startup • Change of target satellite • Monitoring current status • Setting antenna manual search • Setting antenna set skew • Setting antenna search parameter •...
-
Page 5: Installation Kit
INSTALLING THE ANTENNA Installation Kit Contains the items required for securing the antenna unit and ACU to your vessel. Q’ty Description Size Remark Self-Tapping Table Mount 4 x 16 Screw Bracket Rack Mount Flat Head Screw M4 x 12L Bracket ACU Table Mount Sems Bolt M3 x 12L... - Page 6 – Marine Satellite Television System Item Image Q’ty Description Size Remark USB Cable 1.8m ACU to PC (A-A) Rubber Gland Antenna Cables Hex Socket M6 x 40L Radome (Top-Bottom) Head Cap Radome Spring Washer (Top-Bottom) Radome Flat Washer (Top-Bottom)
-
Page 7: Planning The Installation
INSTALLING THE ANTENNA Planning the Installation Selection of Antenna Installation Site Install the antenna in accordance with the following procedures to ensure maximum performance of the antenna. The ideal antenna site should have a clear view of the horizon or satellite all around it. Please be sure there are no obstacles within 15º... - Page 8 RF Cables (Customer Supplied) Due to signal losses across the length of the RF coax on L-Band, Intellian recommends the following 75 ohm coax cable types for standard system installations. For cables that run longer than 100 meters, please consult Intellian Technologies.
-
Page 9: Pin Signal
INSTALLING THE ANTENNA • NMEA 0183 Connector Signal NMEA 0183 - NMEA 0183 + • GPS Connector ACU GPS In/Out Port D-Sub 9 pin Female Signal GPS OUT + GPS IN + • NMEA 2000 Connector Pins Sockets Connector Threads Connector Threads Male Connector Female Connector... -
Page 10: Tools Required For Installation
– Marine Satellite Television System Tools Required for Installation 11 mm Spanner Power Drill 13 mm Spanner Cross Head Screwdriver 19 mm Spanner Flat Head Screwdriver 13 mm Drill Bit 5 mm Allen/Hex key... -
Page 11: Antenna Installation
INSTALLING THE ANTENNA Antenna Installation Unpacking the Wooden Crate of t110W/t130W The antenna pedestal is shipped completely assembled in its radome. Remove the four shipping bolts which mount the antenna to the pallet. The pallet should be lifted by means of a suitable sized lifting equipment. - Page 12 Intellian strongly recommends to restrain the antenna pedestal properly while underway when power is removed from the antenna. The normal operating condition for the t110W/t130W is to remain powered up at all times.
-
Page 13: Antenna Dimensions
INSTALLING THE ANTENNA Antenna Dimensions The method of installation and mounting of the antenna may vary with vessel design but the following procedures are applicable in most situations, and will result in a secure and effective installation. Confirm the height and diameter of the antenna before installing it. - Page 14 – Marine Satellite Television System Preparing Antenna Supporting Pole Mounting Plate Min. 1 cm (0.4”) Max. 3 cm (15”) Support Pedestal Appr. Ø25.4 cm (10”) WARNING: Ensure that cables have been run through watertight fittings to prevent water entry into the vessel when installation is completed.
- Page 15 INSTALLING THE ANTENNA Mounting the Radome Bolt the radome base directly to the support pedestal. Makesure to use the Intel- lian supplied bolts from the accessory box when you mount the radome.
- Page 16 – Marine Satellite Television System Installing the System Cables The coax cables must be inserted through the cable strain relief(s) at the base of the radome. The cables must be routed from the antenna through the deck and through various ship spaces to the antenna control unit. When pulling the cables in place, avoid sharp bends, kinking, and the use of excessive force.
- Page 17 When all the hardware and cables have been installed, turn on the power switch. Use an RG11 rubber gland if you’re using an RF11 cable instead of an RG6 cable supplied by Intellian.
