Configuration attributes
Configuration actions
Three types of configuration are present in the Crocus CNV:
• the non-active configuration
• the active configuration
• the default configuration.
When configuring the Crocus CNV with TMA, as in Chapter 5 - Step-by-step configuration, the following
happens:
Phase
1 The computer running TMA is connected
to the Crocus CNV.
2 Modifications are made on the non-active
configuration.
3 All necessary modifications are carried out
on the non-active configuration.
Execute the Activate Configuration action.
4
crocusIfConv<2m/Nx64><Tt/Cv>/Activate Configuration
If you execute this action, the editable non-active configuration becomes the active configuration.
To activate a configuration, proceed as follows:
Step
1 In the TMA window, select the top object crocusIfConv<2m/Nx64><Tt/Cv> and the group
Configuration.
2 In the action window of TMA, click the left mouse button on Activate Configuration so that
this action is selected.
3 Press the right mouse button and select Execute.
The Activate Configuration action can also be performed with the Send all attributes to device button:
82
Action
Action
Result
The non-active configuration is displayed
on the screen.
These modifications have no immediate
influence on the active configuration
currently used by the Crocus CNV.
Now, the non-active configuration has to
be made active.
The non-active configuration becomes the
active configuration.
