Step-by-step configuration
5.2.1 The load default configuration DIP switch
The location of the load default configuration DIP switch is:
DIP switch name
load default
configuration
To load the default configuration using the appropriate DIP switch, proceed as follows:
Step
1 In case of a ...
• TT, open the housing as described in Section
settings of the Table
• CV, remove the card from the CN4 card nest as described in Section
Changing DIP switch and strap settings of the Card
2 In case of a ...
• TT, set DIP switch bank DS5 position 2 to off. To locate this DIP switch bank, refer to
Section
• CV, set DIP switch bank DS5 position 1 (for converter A) and / or 2 (for converter B)
to off. To locate this DIP switch bank, refer to Section
switches on the Card
3 In case of a ...
• TT, close the housing without fastening the screws.
• CV, insert the card in the CN4 card nest without fastening the screws.
⇒ The Crocus CNV reboots and loads the default configuration.
4 Activate the loaded default configuration:
1. Open a TMA session on the Crocus CNV (refer to Section
Crocus CNV with
2. Execute the Activate Configuration command.
( )
If you are performing this load default configuration procedure because you
accidentally made a configuration error, you have the possibility to retrieve this
erroneous configuration before executing the Activate Configuration command. In that case
you do not have to reconfigure the complete device again, but you only have to correct
the error in question. Retrieve the erroneous configuration by executing the Load saved
configuration command.
5 Reset the corresponding DIP switch to on. Refer to step 2.
6 In case of a ...
• TT, close the housing.
• CV, insert the card in the CN4 card nest.
⇒ The Crocus CNV reboots in normal operation mode.
56
DS5 no.
1 (CV-A)
2 (CV-B & TT)
Top.
3.1.1 - Location of the DIP switches and straps on the Table
Version.
( )
TMA).
Setting
on Normal operation.
off Load default configuration.
Action
3.1.4 - Changing DIP switch and strap
Version.
3.2.1 - Location of the DIP
Crocus CNV
Function
3.2.5 -
Top.
4.2 - Connecting to a
