Crocus CNV

11.2 Downloading with TML

When downloading with TMA (as explained in the previous section), you actually evoke TML (Total
Memory Loader) through TMA. You can also use TML without opening TMA.
To download firmware with TML, proceed as follows:
Step
1 Connect a serial port of your computer
(e.g. COM1) through a straight DB9
male - female cable with the auxiliary
connector of your Crocus CNV as
shown in the following figure:
2 Open a DOS window on your computer.
3 Go to the directory where the TML executable is located. Typically this is
C:\Program Files\TMA.
4 Place the firmware file you want to download in this directory.
5 Type the following command:
where ...
•
tml
devices through their auxiliary port
•
-c1
example COM1)
•
returns graphical information on the download status
-v
•
-f<Txxxxxxx.00>
•
CONTROL
CNV.
To see a list of all the possible TML options: type
the ENTER key.
6 If you press the ENTER key, the firmware download begins.
If you used the –v option together with the TML command, a graphical bar shows the
download progress.
Reference manual
tml -c1 –v -f<Txxxxxxx.00>@CONTROL
is the executable (Total Memory Loader) to download files to the OneAccess
specifies the COM port of the computer connected to the Crocus CNV (in this
is the firmware file you want to download (e.g. T1212001.00)
(in capitals!) specifies that the destination is a flash bank of the Crocus
Action
in your DOS windows and press
TML
Firmware download
