DIP switches and straps of the Crocus CNV
3.1.2 DIP switches of the Table Top
DIP switch bank DS5
The following table gives an overview of DIP switch bank DS5 of the TT:
DIP switch name
start-up mode
load default
configuration
X21 Tx clock
polarity inversion
-
DIP switch bank DS3
The following table gives an overview of the DIP switches on DIP switch bank DS3:
DIP switch name
signal B – earth
(PGND) connection
(1)
DS3 switch 2 only has effect on the RJ45 connector. For the BNC connectors, the transmit B signal is
always connected to the earth.
32
DS5 no. Setting
1
2
3
4
DS3 no. Setting
1
(1)
2
on Start up from flash memory.
off Start up in boot mode.
Normal operation.
on
off Load default configuration.
Inverted X21 Tx clock polarity.
on
off Normal X21 Tx clock polarity.
- - Factory setting. Do not change! -
on The receive B signal (RxB) of the
onboard G703 interface is
connected to the earth.
off The receive B signal (RxB) of the
onboard G703 interface is
disconnected from the earth.
on The transmit B signal (TxB) of the
onboard G703 interface is
connected to the earth.
The transmit B signal (TxB) of the
off
onboard G703 interface is
disconnected from the earth.
Crocus CNV
Function
Function
User manual
