Configuration attributes
crocusIfConv<2m/Nx64><Tt/Cv>/management/consoleNoTrafficTimeout default: 30m 00s
You can open a TMA session on the Crocus CNV through the auxiliary connector. These sessions close
automatically if there is no user interaction during a certain time-out period. This time-out period can be
set with the consoleNoTrafficTimeOut attribute.
The purpose of such a timer is to protect the Crocus CNV against unauthorised access in case the last
user did not close his session.
The consoleNoTrafficTimeOut value ranges from 00000d 00h 00m 00s up to 24855d 03h 14m 07s.
crocusIfConv<2m/Nx64><Tt/Cv>/management/ctrlPortProtocol
The setting of the console attribute depends on what purpose the auxiliary connector of the Crocus CNV
has to serve. This is explained in the following table:
Value
management Select this value if you want to connect the auxiliary connector of the Crocus CNV
to ...
• the Orchid 1003 LAN for management purposes.
• the auxiliary connector of another Crocus CNV using a crossed cable (i.e. they
When connecting the auxiliary connector of the Crocus CNV to a COM port of your
computer, you can still open a TMA session on the Crocus CNV. You can however
not open a CLI or ATWIN session.
console
Select this value if you want to connect the auxiliary connector of the Crocus CNV
to a COM port of your computer in order to manage the Crocus CNV using TMA,
CLI or ATWIN.
The console attribute is present on the Table Top only, not on the Card Version. This because the
management connection between the Crocus CNV CV and the Orchid 1003 LAN happens through the
high speed bus on the CN4 backplane instead of through the auxiliary connector.
This implies that the auxiliary connector of the Crocus CNV CV ...
• can not be connected to:
− the Orchid 1003 LAN for management purposes
− the auxiliary connector of another Crocus CNV to create an extended management link.
• can be connected to a COM port of your computer in order to manage it with TMA, CLI or ATWIN.
94
are connected back-to-back) in order to create an extended management link.
For more information on extended management links, refer to the previous table.
Description
Crocus CNV
default: console
