OneAccess Crocus CNV User And Reference Manual page 24

Installing and connecting the Crocus CNV
2.5.1 Table Top connections
All the connections have to be made at the back of the Crocus CNV Table Top. The following figure gives
a rear view of the Crocus CNV TT.
ON OFF
1
PWR
~
ON OFF
- 48V +
1
PWR
The following table labels the different parts located at the back of the Crocus CNV TT.
Number
1 power switch
2 power inlet
3 DTE interface slot
4 G703 onboard interface
5 auxiliary connector (also called control or NMS connector)
14
2
~
2
3
OUT
3
OUT
Part
Crocus CNV
CTRL
5
IN
4
CTRL
5
IN
4
User manual
