Step-by-step configuration
TMA attribute string
A TMA attribute string has the following layout:
crocusIfConv<2m/Nx64><Tt/Cv>/g703OnBoard/longHaul
1 2
The following table explains the TMA attribute string layout.
Number This position displays ...
1 the TMA attribute icon. It indicates that the string which follows is a TMA attribute string.
Two different TMA attribute icons exist:
• a basic attribute icon
• an advanced attribute icon.
For more information refer to Preface – Conventions used in this manual.
2 the attribute name and its position in the containment tree.
In the figure above, the string crocusIfConv<2m/Nx64><Tt/Cv>/g703OnBoard/longHaul means
the following:
• the attribute name is longHaul
• this attribute is located in the sub object g703OnBoard
• this sub object is located in the top object crocusIfConv<2m/Nx64><Tt/Cv>.
3 the default value of a configuration attribute.
54
Crocus CNV
default: enabled
3
User manual
