DIP switches and straps of the Crocus CNV
DIP switch bank DS3
The following table gives an overview of the DIP switches on DIP switch bank DS3:
DIP switch name
signal B – earth
(PGND) connection
for converter A
DIP switch bank DS4
The following table gives an overview of the DIP switches on DIP switch bank DS4:
DIP switch name
signal B – earth
(PGND) connection
for converter B
40
DS3 no. Setting
1
2
DS4 no. Setting
1
2
on The receive B signal (RxB) of the
onboard G703 interface of
converter A is connected to the
earth.
off The receive B signal (RxB) of the
onboard G703 interface of
converter A is disconnected from
the earth.
on The transmit B signal (TxB) of the
onboard G703 interface of
converter A is connected to the
earth.
The transmit B signal (TxB) of the
off
onboard G703 interface of
converter A is disconnected from
the earth.
on The receive B signal (RxB) of the
onboard G703 interface of
converter B is connected to the
earth.
off The receive B signal (RxB) of the
onboard G703 interface of
converter B is disconnected from
the earth.
on The transmit B signal (TxB) of the
onboard G703 interface of
converter B is connected to the
earth.
off The transmit B signal (TxB) of the
onboard G703 interface of
converter B is disconnected from
the earth.
