Step-by-step configuration
5.5.1 Configuring the RTS control (RS530, V35, V36)
crocusIfConv<2m/Nx64><Tt/Cv>/<dteInterface>/rtsControl
Use the rtsControl attribute to define which device will activate the RTS signal.
Normal operation requires the RTS signal (circuit 105) to be active before the Crocus CNV activates its
data transfer state, as indicated by the CTS signal (circuit 106). Therefore, make sure the RTS signal is
activated either by the application or by the Crocus CNV.
If RTS control is
set to ...
external
internal
68
the RTS signal is Use this setting in case ...
activated by ...
the application. the application has to be in command of the RTS signal.
the Crocus CNV. the application is not able to activate the RTS signal.
Crocus CNV
default: external
