OneAccess Crocus CNV User And Reference Manual page 112

Status attributes
crocusIfConv<2m/Nx64><Tt/Cv>/g703OnBoard/testStatus
This attribute displays the status of the active test. The possible indications are:
Value
progressing The test is starting.
running
The test is running.
ending The test is ending.
unknown There are two possibilities:
• No test is running.
• For some reason it is not possible to retrieve the status of the test.
Normally when an RDL test is started on a local device, the testStatus changes from progressing to running
after the remote device has acknowledged that the RDL test has been initiated successfully. However,
because of the characteristics of the chip used in the Crocus CNV, the testStatus indicates running
immediately after starting the RDL test on the local Crocus CNV. In other words, there is no guarantee
that the RDL test was initiated successfully on the remote Crocus CNV.
This remark applies to the Crocus 2M CNV and the Crocus Nx64 CNV running in unframed mode.
crocusIfConv<2m/Nx64><Tt/Cv>/g703OnBoard/errorCount
This attribute displays the amount of detected errors since the start of an ET, AL-ET or RDL-ET test.
Every time a new ET, AL-ET or RDL-ET is started, the errorCount attribute is reset to 0.
crocusIfConv<2m/Nx64><Tt/Cv>/g703OnBoard/lineAttenuation(dB)
This attribute displays the current G703 line attenuation in dB, e.g. 11.0.
crocusIfConv<2m/Nx64><Tt/Cv>/g703OnBoard/ifDescr
This attribute displays the interface description (g703OnBoard). It is an SNMP MIB2 parameter.
crocusIfConv<2m/Nx64><Tt/Cv>/g703OnBoard/ifType
This attribute displays the interface type (other). It is an SNMP MIB2 parameter.
crocusIfConv<2m/Nx64><Tt/Cv>/g703OnBoard/txdItu103
This attribute displays the status (on / off) of the transmit data signal (circuit 103). The txdItu103 attribute
only indicates the presence of the TxD signal, it does not monitor the real data signal.
crocusIfConv<2m/Nx64><Tt/Cv>/g703OnBoard/rxdItu104
This attribute displays the status (on / off) of the receive data signal (circuit 104). The rxdItu104 attribute
only indicates the presence of the RxD signal, it does not monitor the real data signal.
102
Description
Crocus CNV
Reference manual
