VBOX II User Guide
7. Connect the power cable/ battery pack to the 8. If using 12v power cable, connect to vehicle
VBOX
9. With the power applied, the red PWR led should illuminate. The VBOX II will start
searching for satellites. The ST led will indicate the number of satellites currently in lock.
For best results ensure the VBOX has acquired a lock on 5 or more satellites, essential for
quality signal reception. When using the VBOX for the first time or when using the VBOX
after a long period of time, allow the VBOX to sit for between 5 and 10 minutes to re-
collect data needed to track satellites.
As the vehicle begins moving, the blue CF led should begin to flash as data is recorded to
compact flash, if inserted. When the vehicle comes to a stop, the blue CF led should
extinguish. The card can now be removed and the data transferred onto the PC for
analysis. If no compact flash card is fitted then data will be recorded to the internal RAM.
NOTE before using the Internal RAM, the RAM should be cleared. See section 'Setup' of
the VBOX Software manual.
