CAN Bus data format
ID**
Update
Data Bytes
rate
1
0x301
50ms
(1) Sats in
view
0x302
50ms
(4) Position – Longitude DDMMM.MMMMM
0x303
50ms
(7) Altitude. WGS 84. (Metres)
0x304
50ms
(11) Distance. (Meters)
0x305
50ms
(14) Distance travelled since VBOX reset
**Default Identifiers. The identifier values can be changed using the configuration software.
(1) If Satellites in view < 3 then only Identifier 0x301 transmitted and bytes 2 to 8 are set to 0x00.
(2) Time since midnight. This is a count of 10mS intervals since midnight UTC. (5383690 = 53836.90 seconds since midnight or 14 hours, 57
minutes and 16.90 seconds)
(3) Position, Latitude * 100,000 (515924579 = 51 Degrees, 59.24579 Minutes North). Latitude highest bit indicates north/south hemisphere.
0=north, 1=south, Bit 7 in Status is also set.
(4) Position, Longitude * 100,000 (5882246 = 0 Degrees, 58.82246 Minutes West). Longitude highest bit indicates east/west of Greenwich
meridian. 0=west,1=east. Bit 6 in Status is also set.
(5) Velocity, 0.01 knots per bit.
(6) Heading, 0.01° per bit.
(7) Altitude, 0.01 meters per bit, signed.
(8) Vertical Velocity, 0.01 m/s per bit, signed.
(9) Status. 8 bit unsigned char. Bit 0=VBOX Lite, Bit 1=Open or Closed CAN Bus (1=open), 2=VBOX3
(10) Status is an 8 bit unsigned char. Bit 0 is always set, Bit 3=brake test started, Bit 4 = Brake trigger active, Bit 5 = DGPS active
(11) Distance, 0.000078125 meters per bit, unsigned.
(12) Longitudinal Acceleration, 0.01G per bit, signed.
(13) Lateral Acceleration, 0.01G per bit, signed.
(14) Distance travelled in meters since VBOX reset.
(15) Time from last GPS sample to brake trigger event.
(16) Velocity at brake trigger point in Knots.
The VBOX CAN database is available in Vector Database (DBC File) format on request from Racelogic
2
3
4
(2) Time since midnight UTC
(8) Vertical velocity. (M/S)
Page 22 of 23
5
6
(3) Position – Latitude DDMM.MMMMM
(5) Velocity. (Knots)
Unused
(12) Longitudinal Accel. (G)
(15) Trigger time
7
8
(6) Heading. (Degrees)
(9) Status
(10) Status
(13) Lateral Accel. (G)
(16) Trigger Velocity
