Networking Devices
Selecting Actions for Devices
6-4
View Alerts—Displays the Alerts page with any alerts that have occurred
I
for the device.
I Check Connectivity (Ping)—Use ping to test the network connection to
a device.
I Set Friendly Name—Create an easy-to-remember name for a device.
I Update Discovery—Re-reads the configuration of the selected network
device or devices to see if changes have occurred.
Add to Custom Group—Add a device to a custom group.
I
I Delete—Delete the selected device from the devices page.
I Find in Topology View—Locate a device in the Topology View.
I Security (Set SNMP Passwords - Communities)—Set up device security
by entering passwords.
Configuration—Set the thresholds for SNMP traps. Only
I SNMP/Trap
appears for switches with browser interfaces.
Update Firmware—Download the latest device firmware (see
I
loading Firmware
I Telnet—Start a telnet session with a device (available only for devices
that support telnet).
I Node Port Table—View a table showing the devices attached to each port
of the selected device.
Management Home Page—Displays the Status page for the selected
I
device.
Properties—Display some generic SNMP information about the device
I
including the system name, IP/IPX address, uptime, device description
and status.
You can perform actions on up to 100 devices at a time. Use Ctrl-click to select
more than one device from the list.

SNMP/Trap Configuration

In order for traps to function, you must set the trap in the Thresholds dialog
box. You must be at the management station to set traps. This menu selection
only appears for switches that are browser-manageable. Do the following:
Select SNMP/Trap Configuration from the Actions menu.
1.
2. In the Device Configuration dialog box select the Thresholds tab and set
the thresholds for the traps you are interested in receiving.
• Threshold—the value of the event at which the trap or alarm is
triggered
• Tolerance—the device does not send another event to the manager
until the value goes below the tolerance value and the threshold value
is reached again. The default is 80% of the threshold value.
• Time Interval—the time elapsed while HP TopTools examines speci-
fied traffic for threshold and tolerance violations. If the threshold is
reached with the time interval specified, an event is triggered.
for instructions).
Down-
