You can create one or more backup links by selecting the Backup Links button
and clicking on the Add New Backup Link... button at the bottom of that page.
The parameters are described in the following table.
Table 12-4. Backup Link Parameters
Parameter
Status
Primary Port
Backup Port
MAC Address
Test Time
Retries
Configuring Load Balancing—Switching Hubs
Only the switching hubs provide a load balancing feature to automatically
distribute the switching hub ports among the four segments to optimize
performance. This feature requires a switch module.
To access this feature, select the Load Balancing button. Click on the Perform
Automatic Load Balancing button. If you want to undo the load balancing, select
the Undo Last Load Balancing button.
Description
Displays which port is currently being used, a primary port or
a backup port.
A port that you can use as a primary port, or the port that will
be used during standard connection of a hub and the
connected device.
The backup port to be used if there is a failure on the primary
port. If the primary port is active, the backup port is inactive.
The MAC address of the device to which you have a backup
(redundant) path. It is the recipient of the 802.2 test packets,
which are used to verify the primary path.
The interval in seconds between test packets sent between
the primary port and the receiving device.This checks the
integrity of the link to determine whether to initiate a backup
link. The number can be between 1 and 15.
The maximum number of times the test packets from the
primary port fail to return from the other device before the
backup port becomes the active port.
