Section 6: Using the Epilog Dashboard
General Tab
Job Type
One of the first things new users want to know is how the laser system knows
when to engrave and when to cut. The decision is based on several variables:
1) Line weight (or Stroke) as defined in your graphic image from Corel,
2) The Resolution as set in the DashBoard driver will also have an effect
3) The Job Type as set in the DashBoard driver - Raster, Vector or
Raster Mode – This mode will only engrave. Vector lines will not be processed
from this mode.
Vector Mode – This mode will only vector. Raster images will not be processed
from this mode.
Combined Mode – By properly setting up your artwork you can both engrave
and cut from this mode.
Illustrator, etc. The line weight of your object will determine if it will
engrave or cut.
on which lines will engrave and which will cut.
Combined.
To make things easy on themselves, most users set their lines for vector
processing as a Hairline (0.003") and make the lines red. This provides
a very clear indicator that there is a vector line in the artwork.
