Section 10: Standard & Optional Machine
Features
The pump can either be purchased through
your Epilog representative or you can
connect your existing compressed air
supply to the ¼ inch (6 mm) receptacle at
the back of the machine (30PSI max).
Air assist should always be activated
during vector cutting operations to reduce
the risk of fire!
Optional Air Assist pump.

Front Access Door

The front access door is usually used for easy loading and unloading of palletized
materials. The door is interlocked and the laser will not fire if the door is open.
The front access door is supported by struts.
The struts can be disconnected if you wish to open the door more than its standard 90
degree opening. Remove the left and right thumb screws to allow the door to open the
full 180 degrees.
108
