Connecting Electrical Power

All Epilog laser systems have an auto-switching power supply that detects the
incoming voltage and automatically switches itself to operate properly at any
single-phase voltage between 100 and 240 VAC. The power supply will also
automatically compensate for either 50 or 60 Hz. Epilog supplies the appropriate
power cord for all of our equipment. The electrical cord is found in the accessory
package with your machine. It is recommended that a dedicated 15 amp circuit be
used if available, but it is not required.
The 60 watt and 75 watt machines draw more current than the lower wattage
lasers. These two systems can operate on 110 volts, but most users find that a 200
V connection is more efficient.
The electrical connection is found at the lower back of the machine.
Electrical
Connection
(110/220V - 50/60 Hz)
Section 3: Getting Started
Exhaust Blower
Roof or exterior wall
4" (100 mm) flexible aluminum duct
or rigid galvanized sheet
metal (Do not use vinyl,
plastic or "soft" flexible duct).
9
