• Mode 5 : Hardware Triggered Strobe.

The counter will start counting after the rising edge of the

trigger input and will go low for one clock period when the

terminal count is reached. The counter is re-triggerable. the

output will not go low until the full count after the rising edge

of any trigger.

The detailed description of the mode of 8254, please refer the Intel

Microsystem Components Handbook.

80 • • 8254 Programmable Interval Time
