ADLINK Technology NuDAQ PCI-6308 Series User Manual

Isolated analog output board
Hide thumbs Also See for NuDAQ PCI-6308 Series:

Advertisement

Quick Links

Download this manual
®
NuDAQ
PCI-6308 Series
Isolated Analog Output Board
User's Guide
Recycled Paper

Advertisement

loading
Need help?

Need help?

Do you have a question about the NuDAQ PCI-6308 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ADLINK Technology NuDAQ PCI-6308 Series

Summary of Contents for ADLINK Technology NuDAQ PCI-6308 Series

  • Page 1 ® NuDAQ PCI-6308 Series Isolated Analog Output Board User's Guide Recycled Paper...
  • Page 2 Trademarks NuDAQ, DAQBench are registered trademarks of ADLINK Technology Inc. Other product names mentioned herein are used for identification purposes only and may be trademarks and/or registered trademarks of their respective...
  • Page 3 Getting service from ADLINK Customer Satisfaction is the most important priority for ADLINK Tech Inc. If you need any help or service, please contact us. ADLINK Technology Inc. Web Site http://www.adlinktech.com Sales & Service Service@adlinktech.com NuDAQ + USBDAQ nudaq@adlinktech.com Technical Automation automation@adlinktech.com...

  • Page 5: Table Of Contents

    Table of Contents Introduction ................1 Features ................2 Applications ..............2 Specifications ..............3 Software Supporting ............6 1.4.1 Programming Library ..........6 ® 1.4.2 PCIS-LVIEW: LabVIEW Driver ........ 7 1.4.3 PCIS-VEE: HP-VEE Driver........7 1.4.4 DAQBench : ActiveX Controls ........ 7 1.4.5 DASYLab PRO.............
  • Page 6 Operation Theory ...............20 Voltage Output ............... 20 4.1.1 Voltage Output Range Selection......20 4.1.2 DA data format ............21 Analog Output Status Register......... 22 Current Output and Range Control........22 Isolated Digital Output ............. 23 Isolated Digital Input ............23 C/C++ Library ..............24 Libraries Installation ............

  • Page 7: How To Use This Guide

    How to Use This Guide This manual is designed to help you use the PCI-6308. It describes how to configure and control various functions of the PCI-6308 card. It is divided into six chapters: Chapter 1, “Introduction”, gives an overview of the product features, applications, and specifications.

  • Page 9: Introduction

    Introduction The PCI-6308 series products are isolated analog output cards. The PCI- 6308 series includes the follow three cards: l PCI-6308V: Isolated 8-CH voltage output card l PCI-6308A: Isolated 8-CH voltage and current output card l PCI-6304V: Isolated 4-CH voltage output card The PCI-6308V is a high-performance, 12-bit analog output board with PCI interface.

  • Page 10: Features

    1.1 Features • 32-bit PCI-Bus, Plug and Play, complies with PCI local bus specification Rev 2.1 • 8-CH 12-bit voltage output • Fully isolation protection from PC power to external device • 2500Vrms isolation voltage • Unipolar or bipolar voltage output range •...

  • Page 11: Specifications

    1.3 Specifications Voltage Output • Numbers of channel: 8 channel for PCI-6308V and PCI- 6308A • Converter: DAC4814AP or equivalent • Conversion type: Monolithic multiplying • Resolution: 12-bit no missing code (11-bit guarantee) • Voltage output range: (jumper selectable) Bipolar: ±10V Unipolar: 0~10V User defined unipolar: 0~ user defined voltage.
  • Page 12 Current Output • Numbers of channel: 8 channel for PCI- 6308A • Current output range: 0~20mA, 4~20mA, 5~25mA. (Software programmable) • Voltage to current converter: B.B. XTR110 or equivalent • Settling time: 17 µ second (0~20mA) • Slew rate: 1.3mA / µs •...
  • Page 13 Power Supply source • +15V output (Pin #7 on CN1): 200mA maximum (for PCI-6308V) 20mA maximum (for PCI-6308A, when all current output channel is 25mA) • -15V output (Pin #25 on CN1): 200mA maximum (for PCI-6308V) 20mA maximum (for PCI-6308A, when all current output channel is 25mA) General Specifications •...

  • Page 14: Software Supporting

    1.4 Software Supporting ADLINK provides versatile software drivers and packages for users’ different approach to building a system. We not only provide programming libraries such as DLL for many Windows systems, but also provide drivers for many ® software package such as LabVIEW , HP VEE , DASYLab , InTouch...

  • Page 15: Dasylab Tm Pro

    ® 1.4.2 PCIS-LVIEW: LabVIEW Driver PCIS-LVIEW contains the VIs, which are used to interface with NI’s LabVIEW® software package. The PCIS-LVIEW supports Windows 95/98/NT/2000. The LabVIEW® drivers is shipped free with the board. You can install and use them without a license. For more information about PCIS-LVIEW, please refer...

  • Page 16: Pcis-Icl: Incontrol

    1.4.8 PCIS-ICL: InControl Driver PCIS-ICL is the InControl driver, which supports Windows NT. The PCIS-ICL is included in the ADLINK CD. A license is needed to use the drivers. 1.4.9 PCIS-OPC: OPC Server PCIS-OPC is an OPC Server, which can link with OPC clients. There are several software packages on the market, which can provide the OPC clients.

  • Page 17: Installation

    Installation This chapter describes how to install the PCI-6308. Please follow the following steps to install the PCI-6308 family of products. • Check what you have (section 2.1) • Unpacking (section 2.2) • Check the PCB and jumper location (section 2.3) •...

  • Page 18: Unpacking

    2.2 Unpacking The PCI-6308 series card contains electro-static sensitive components that can be easily be damaged by static electricity. Therefore, the card should be handled on a grounded anti-static mat. The operator should be wearing an anti-static wristband, grounded at the same point as the anti-static mat.

  • Page 19: Pci-6308V Layout

    2.3 PCI-6308V Layout Figure 2.1 PCI-6308V Layout Installation • 11...

  • Page 20: Hardware Installation Outline

    2.4 Hardware Installation Outline 2.4.1 Hardware configuration The PCI cards (or CompactPCI cards) are equipped with plug and play PCI controllers, it can request base addresses and interrupts according to the PCI standard. The system BIOS will assign the system resources based on the PCI cards’...

  • Page 21: Device Installation For Windows Systems

    2.5 Device Installation for Windows Systems Once Windows 95/98/2000 has started, the Plug and Play functions of the Windows system will find and locate the new NuDAQ/NuIPC card. If this is the first time a NuDAQ/NuIPC card is installed in your Windows system , you will be prompted to input the device information source.
  • Page 22 Legend: the voltage output of channel n for PCI-6308V/6308A, n=0~7 for PCI-6304V, n=0~4 the current output of channel n An is used by the PCI-6308A only, n=0~7 ExtVref: external reference voltage for voltage output AGND: Ground of analog output channels and +/-15V -15V: -15V voltage output +15V:...

  • Page 23: Jumper Setting

    Jumper Setting The PCI-6308‘s voltage output channels can be configured with different voltage range. Each output channel and its corresponding jumpers are listed below. Corresponding Jumper Corresponding Jumper Channel For output mode For reference voltage (Unipolar/Bipolar) sources (external/internal) JP11 JP11 JP11 JP11 JP10...

  • Page 24: Termination Board Connection

    2.8 Termination Board Connection The PCI-6308 is equipped with a DB-37 connector. The available termination boards include: • ACLD-9137: A general purposed 37-pin screw terminal. The ACLD- 9137 has a DB-37 male connector, which is used to directly attach to the PCI-6308.

  • Page 25: Registers

    Registers The descriptions of the registers and structure of the PCI-6308 Series are outlined in this chapter. The information in this chapter will assist programmers, who wish to handle the card with low-level programs. In addition, the low level programming syntax is introduced. This information can help beginners to operate the 743X in the shortest possible time.

  • Page 26: I/O Address Map

    3.2 I/O Address Map Most of the PCI-6308 registers are 16 bits. Users can access these registers using 16-bit I/O instructions. The following table shows the registers map, including descriptions and their offset addresses relative to the base address. I/O Address Write Read Base + 00h...

  • Page 27: Digital Output Register

    3.4 Digital Output Register D0~D3 is the digital output signal written to the output channel. D4~D7 don’t care. Address: BASE + 40(hex) Attribute: write only Data Format: BASE+20 3.5 Digital Input Ports D4~D7 is the digital input signal from CN1. D0~D3 is read back signal from the digital output channel.

  • Page 28: Operation Theory

    Operation Theory In this chapter, the detail operation theory of the PCI-6308V and PCI-6308A is described. Before programming or applying the PCI-6308 card to your application, please go through this chapter to understand the features first. 4.1 Voltage Output There are 8 voltage output channels for PCI-6308V and 6308A. For voltage output operation, you have to understand: How to set the voltage output range.

  • Page 29: Data Format

    4.1.2 DA data format The DA data format is a 12-bit unsigned value for all channels, that is, the value is in binary format. The digital value range from 0(0X000) to +4095(0xFFF) corresponds to the full span of the output range, which is set by the jumpers.

  • Page 30: Analog Output Status Register

    4.2 Analog Output Status Register The DAC uses a series bus architecture hence there is a delay in the output of the digital value. The data transfer time for every DA data write takes 16µs, therefore the software driver must wait for 16µs before sending another set of data to any analog output port.

  • Page 31: Isolated Digital Output

    Input Voltage Output Current Mode Range Range 0~10V 0~20 mA 0~10V 5~25 mA 0~10V 4~20 mA 4.4 Isolated Digital Output The isolated digital output circuits have the following characteristics. The output is of an open collector type. The isolation voltage between the isolated output and the host power signals is 2500 Vrms.

  • Page 32: C/C++ Library

    C/C++ Library This chapter describes the software library for operating this card. Only the functions in the DOS library and Windows 95 DLL are described. Please refer to the PCIS-DASK function reference manual, which is included in the ADLINK CD, for descriptions of Windows 98/NT/2000 DLL functions. Function prototypes and useful constants are defined in the header files of the LIB directory (DOS) and INCLUDE directory (Windows 95).

  • Page 33: Programming Guide

    5.2 Programming Guide 5.2.1 Naming Convention There are 7 function calls provided by the C Language Library. All the functions of the PCI-6308 are covered in this library. The functions of the PCI-6308 software driver use full-names to represent the functions' real meaning.

  • Page 34: 6308_Initial

    _6308_Initial @ Description This function is used to initialize the PCI 6308. Every PCI_6308 has to be initialized by this function before calling other functions. @ Syntax C/C++ (DOS) U16 _6308_Initial (U16 *existCards, PCI_INFO *pciInfo) C/C++ (Windows 95) U16 W_6308_Initial (U16 *existCards, PCI_INFO *pciInfo) Visual Basic (Windows 95) W_6308_Initial (existCards...
  • Page 35 _6308_DA @ Description This function is used to write data to the D/A converters. There are 8 Digital-to-Analog conversion channels on the PCI-6308. The resolution of each channel is 12 bits unsign; i.e. the digital value range from 0 (0x000) to +4095 (0xFFF). Please refer to section 4.1.2 for details of the DA data format.
  • Page 36 _6308_DA_0_3 @Description This function is used to simultaneously write data to the D/A converters of channel 0 to channel 3. The resolution of each channel is 12 bits unsign; i.e. the digital value range from 0 to 4095. Please refer to section 4.1.2 for details of the DA data format.
  • Page 37 _6308_DA_4_7 @Description This function is used to simultaneously write data to the D/A converters of channel 4 to channel 7. The resolution of each channel is 12 bits unsign; i.e. the digital value range from 0 to 4095. Please refer to section 4.1.2 for details of the DA data format.

  • Page 38: 6308_Get_Da_Status

    _6308_Get_DA_Status @ Description This function is used to check the DA data sending status. Because the data transfer time for every DA data takes 16.0 µs, the software driver must wait for 16.0µs before sending another data to any analog output port. This function should be called before writing any data to the output port.
  • Page 39 _6308_DI @ Description This function is used to read data from the digital input ports. There are 4 digital input channels on the PCI-6308. The retrieved value is stored in DIData. @ Syntax C/C++ (DOS) _6308_DI (U16 cardNo, U16 *DIData) C/C++ (Windows 95) U16 W_6308_DI (U16 cardNo, U16 *DIData) Visual Basic (Windows 95)
  • Page 40 5.10 _6308_DO @ Description This function is used to write data to the digital output ports. There are 4 digital output channels on the PCI-6308, i.e. the output value ranges from 0 to 15. @ Syntax C/C++ (DOS) _6308_DO (U16 cardNo, U16 DOData) C/C++ (Windows 95) U16 W_6308_DO (U16 cardNo, U16 DOData) Visual Basic (Windows 95)

  • Page 41: 6308_I2V_Control

    5.11 _6308_I2V_Control @ Description This function is used to set the PCI-6308As’ voltage-to-current mode control. There are three range modes for the PCI-6308A. Please refer to section 3.3 for details of the voltage to current conversion. The three voltage-to-current modes are: Input Voltage Output Current Mode...

  • Page 42: Warranty Policy

    Warranty Policy Thank you for choosing ADLINK. To understand your rights and enjoy all the after-sales services we offer, please read the fo llowing carefully. Before using ADLINK’s products, please read the user manual and follow the instructions exactly. When sending in damaged products for repair, please attach an RMA application form.
  • Page 43 Customers are responsible for the fees regarding transportation of damaged products to our company or to the sales office. To ensure the speed and quality of product repair, please download an RMA application form from our company website www.adlinktech.com . Damaged products with RMA forms attached receive priority.
