Loading Thermal Transfer Ribbon

If you plan to use thermal transfer media, you must install a thermal transfer
ribbon (TTR) to print labels in thermal transfer mode.
Note: Save the plastic bag that your ribbon comes in. Attached to the ribbon bag is a
sticker with a three-digit sensitivity number printed on it. You need this information to
set the correct media sensitivity number. See "Setting the Media Sensitivity Number"
in Chapter 3 for more information.
To load thermal transfer ribbon
1. Make sure the printhead is in the raised position. If not, turn the head lift
2. Place the empty ribbon core that comes with the printer on the ribbon
3. Detach the leader from the new thermal transfer ribbon roll and unwind the
4. Slide the roll of thermal transfer ribbon onto the ribbon supply hub with the
5. Route the ribbon leader through the printer mechanism as shown in the
6. Attach the leader from the new thermal transfer ribbon roll to the empty
7. Turn the ribbon rewind hub clockwise until the ribbon runs smoothly
C o d e 39
lever clockwise until it releases the printhead.
rewind hub.
end of the ribbon approximately 8 inches. The edge of the ribbon has a
leader (with an adhesive strip on the leader edge) to guide the ribbon
through the printhead mechanism.
ribbon roll winding clockwise.
illustration.
Note: Make sure that the ribbon goes over the label gap sensor PCB located on the
top of the upper media guide. If the ribbon becomes caught on the PCB, it can cause
the ribbon to wrinkle.
Note: Make sure the ribbon runs above the upper media guide. The ribbon must
come in contact with the printhead.
ribbon core using the adhesive strip on the leader edge.
through the printhead mechanism.
