Cleaning the Printhead

In order for the printhead to provide good print quality, it must maintain close
contact with the media. Therefore, cleaning media debris from the printhead is
very important. Clean after every roll (6,000 inches or 152 m) of media or when
necessary.
Caution
Do not use sharp objects such as knives or screwdrivers to scrape the
printhead clean. Cleaning with sharp objects will damage the printhead.
Clean with only a cotton swab, or a clean, lint-free cloth or tissue damp with
isopropyl alcohol.
Conseil
N'utilisez pas d'objets pointus tels que couteaux ou tournevis pour nettoyer
la tête d'imprimante. Nettoyer avec des objets pointus endommagera la tête
d'imprimante. Nettoyez-la seulement avec de la ouate ou avec un linge propre
et libre de peluches, humecté avec de l'alcool d'isopropyl.
To clean the printhead
1. Turn the ON/OFF switch to the off position.
2. Remove the media cover.
3. Disengage the printhead by rotating the head lift lever clockwise until the
4. Remove the media from the supply roll post and remove the ribbon from
5. Use a cotton swab moistened with alcohol to remove any dirt, adhesive, or
6. Wait 5 to 10 seconds for the print surface to dry.
7. Replace the media and ribbon.
8. Engage the printhead by rotating the head lift lever counterclockwise until
9. Replace the media cover. Turn the ON/OFF switch to the on position.
printhead releases. The printhead raises so you can clean it.
the ribbon supply and rewind hubs.
debris from the print surface on the bottom of the printhead.
it locks in place.
Co de 39 Co de 39
Optimizing Print Quality
