Intermec EasyCoder 501 – User's Manual
RIBBON LOAD
1
Open the front and right-hand doors.
3
Pull out the used-up ribbon and the empty ribbon core.
5a
58 – 60 mm
(2.3")
#1
In case of 58-60 mm ribbon width, compress the unwind
bobbin and move it so it snaps into the 1:st groove.
2
Turn the printhead lift knob to "Load" position.
4
Unpack a roll of Intermec transfer ribbon. The use of any
thermal transfer ribbon, other than those supplied by
Intermec, will invalidate the printhead warranty.
5b
88 – 90 mm
#2
In case of 88-90 mm ribbon width, compress the unwind
bobbin and move it so it snaps into the 2:nd groove.
!
(3.5")
20
